1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift

1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift
1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift

Large Image :  1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Cargo Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Cargo Elevator Load: 1000kg-5000kg
Speed: 0.5m/S Elevator Door: Sider Door
Door Knife: Double Warranty: 12 Months After Shipping
Material: Steel Plate Product Name: Cargo Elevator
Control: VVVF Elevator Control System Keywords: Freight Lift
Product: Cargo Elevator Model: Cargo Elevator

1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift



Load
KG
Speed
m/s
Car specification
CW x CD
Door opening size
JJxOPH
Top floor height
OH
1000
0.5
1400 x 1700
1200 x 2100
4200
1600
0.5
1500 x 2300
1400 x 2100
4200
2000
0.5
1800 x 2300
1500 x 2100
4200
3000
0.5
2000 x 2800
1800 x 2100
4200
4000
0.5
2200 x 3300
2200 x 2300
5000
5000
0.5
2400 x 3600
2200 x 2300
5000







1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift 0



1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift 1



1000kg-5000kg Industrial Warehouse Lift Guide Rail Hydraulic Cargo Elevator Goods Lift Freight Elevator Cargo Lift 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
