Product Details:
Payment & Shipping Terms:
|
Name: | Wheelchair Lift | Load: | 350kg |
---|---|---|---|
Motor Power: | 2.2kw 220V/AC | Elevator Door: | Sider Door |
Guide Rail: | T Guide | Warranty: | 12 Months After Shipping |
Material: | Steel Plate | Product Name: | Wheelchair Lift |
Control: | VVVF Elevator Control System | Keywords: | Wheelchair Lift |
Highlight: | Stair Wheelchair Lift,Home Use Wheelchair Lift,Villa Elevator Wheelchair Lift |
Wheel Chair Elevator Lift Home Use Stair Lift Wheelchair Lift Villa Elevator
Technical parameters:
Multifunction electric barrier lifting platform | ||||
Power supply | 220V/50HZ/25A | |||
Dimensions | 1768mm x 1285mm x L | |||
Lifting plate size | 1370mm x 917mm | |||
Maximum lift height | 10m | |||
Lift the lowest floor height | 80mm | |||
Installation | No pit-mounted (fixed directly to the level of C30 concrete floor, concrete thickness of not less than 200mm) | |||
Lifting speed | 40mm / s (screw driver) 70mm / s (hydraulic drive) | |||
Maximum load | 350(kg) | |||
Fender forms | 90°/180° | |||
Rocker working angle | 75° | |||
Drive mode | Precision screw-driven or driven hydraulic power unit | |||
Control supply voltage | 24V/DC | |||
Motor Power | 2.2kw 220V/AC | |||
Lift Control | Rocker operation run from the reset switch | |||
Overload | Overcurrent relay control | |||
Outbound form | Outbound boxes or columns were installed in the upper and lower layers parked near a wall or floor, the upper and lower linkage platform | |||
For the environment | Indoor or outdoor | |||
Temperature | -20°C — 60°C | |||
Safety devices | Security Rocker | Rocker rise when the device runs automatically tilt, slide platform to prevent wheelchair | ||
Emergency Stop | Press the emergency button switch can control the machine to run up or down | |||
Emergency descent | Hand shake of the operation or use of a manual pressure relief system memory to enable the implementation of the emergency battery emergency lowering function | |||
Safety Net | Lift the floor drops below the safety net in case of an obstacle to stop running immediately dropped |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
