Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators

Large Image : Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	Cargo Goods Elevators

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$7000-12000
Packaging Details:	container
Delivery Time:	15~30 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	500 Set/ Year

Contact Now

Detailed Product Description

Name:	Cargo Goods Elevators	Load:	1000kg-5000kg
Speed:	0.5~1.0m/s	Main & Light Power:	330V/220V 50HZ
Machine Room:	Without Machine Room	Door Knife:	Double
Elevator Door:	Side Opening Door	Deceleration Device:	With Deceleration Device
Model:	Cargo Goods Elevators	Product Name:	Cargo Goods Elevators
Type:	Cargo Goods Elevators
Highlight:	Large Space Room Freight Lifts , Customized Cargo Goods Elevators , Mr/Mrl Freight Lifts

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators

Product Parameters

Capacity	Speed	Inner dimension Axb(mm)	Net to open the door Size(mm)	Shaft Size(mm)	Machine room dimension
Single Door Small Room Elevator
1000(KG)	0.5~1.0(m/s)	1400x1600x2200	1200x2100	2400x2100	2400x2100
2000(KG)	0.5~1.0(m/s)	1900x2100x2200	1600x2100	2900x2600	2900x2600
3000(KG)	0.5~1.0(m/s)	2200x2500x2200	1800x2100	3500x3100	3500x3100
5000(KG)	0.5~1.0(m/s)	2700x3200x2200	2200x2100	4000x3700	4000x3700

Capacity	Speed	Inner dimension Axb(mm)	Net to open the door Size(mm)	Shaft Size(mm)	Machine room dimension
Small Room Less Elevator
2000(KG)	0.5~1.0(m/s)	1900x2100x2200	1600x2100	2900x2600	N/A
3000(KG)	0.5~1.0(m/s)	2200x2500x2200	1800x2100	3500x3100	N/A

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 0

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 1

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 5

Delivery

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 6

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 7

Mr/Mrl Quality Large Space Room Freight Lifts Customized Cargo Goods Elevators 9

1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
