Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service

Large Image : Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	Freight Elevator Cargo Lift

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$7000-12000
Packaging Details:	container
Delivery Time:	15~30 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	500 Set/ Year

Contact Now

Detailed Product Description

Name:	Cargo Elevator	Load:	1600kg-10000kg
Speed:	0.5~1.0m/s	Main & Light Power:	330V/220V 50HZ
Operation System:	Full Collective Selection Operation	Driving System:	VVVF
Elevator Door:	Side Opening Door	Deceleration Device:	With Deceleration Device
Model:	Cargo Elevator	Product Name:	Cargo Elevator
Type:	Cargo Elevator	Attendant:	Without Attendant
Door Knife:	Single,Double	Hairline Style:	Hairline Stainless Steel
Highlight:	Quick Response Cargo Elevator , Delicate Service Cargo Elevator , Hairline Stainless Steel Cargo Elevator

Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service

The ceiling: Glass mirror panel + LED Energy Saving Lamp
Car Wall: hairline stainless steel
Car door: hairline stainless steel
Handrail: Alloy
Car bottom: marblr-like marcromolecule color board

Load	Speed	Cabin size	Door Opening	Shaft size
kg	m/s	CW*CD	EW*EH	HW*HD
1600	1.0	1500*2100	1300*2100	2350*2600
2000	1.0	1600*2600	1500*2200	2700*3100
3000	1.0	2100*2700	1800*2200	3200*3200
5000	0.5	2400*3600	1800*2200	3750*4000
8000	0.5	3600*3800	3600*2800	5700*3800
10000	0.5	3700*4000	3700*2800	5550*4500

Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service 0

Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service 3

Delivery

Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service 4

Hairline Stainless Steel Cargo Elevator Made In China With Quick Response And Delicate Service 5

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
