VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator

VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator
VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator

Large Image :  VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Cargo Goods Elevators
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Cargo Goods Elevators Load: 1000kg-7000kg
Speed: 0.25~1.75m/s Power Supply: AC 380V 3PHASE 50HZ
Machine Room: Without Machine Room Car Wall: Painted Steel Or Hairline Stainless Steel
Elevator Door: Side Opening Door Deceleration Device: With Deceleration Device
Model: Cargo Goods Elevators Product Name: Cargo Goods Elevators
Type: Cargo Goods Elevators
Highlight:

5t Freight Cargo Goods Service Elevator

,

VVVF Vertical Parking Lifts

,

7t Vertical Parking Lifts

VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator





Freight Lift Cargo Goods Elevator Machine room or Machine roomless
Standard or customize
Capacity 1000/2000/3000/4000/5000/7000kg
1/2/3/4/5/7t
Speed 0.25/0.4/0.5/0.63/1.0/1.5/1.75m/s

Usage: for cargo goods freight transportation
Anti-collision strip and light curtain protection
Firm and durable cabin with bumper stripes





Lift Type Cargo Elevator
Machine Room MR/MRL
Rated Load 1000/2000/3000/4000/5000/7000kg
Rated Speed 0.25/0.4/0.5/0.63/1.0/1.5/1.75m/s
Plane size of well Customized
OH Customized
Pit Customized
Cabin Size Customized
Door Size Customized
Production Standard GB7588-2003 Elevator Manufacturing and Safety Specification
and GB10058-88 Elevator Technical Conditions
Power supply AC 380V 3PHASE 50HZ
Lighting Power AC220V 1PHASE 50HZ
Car Wall Painted steel or Hairline stainless steel
Floor Decorative steel plate
Lighting LED
Ventilation Fan
Function Standard

VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 0VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 1VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 2



VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 3



Delivery


VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 4


VVVF 1/2/3/4/5/7t Vertical Parking Lifts Freight Cargo Goods Service Elevator 5



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
