5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate

5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate
5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate

Large Image :  5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Freight Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Freight Elevator Load: 3000~5000kg
Speed: 0.25~0.5m/s Door Type: One Gate / Two Gate
Keywords: Freight Elevator Lift Application: Cargo Lift
Drive Type: AC Material: Stainless Steel
High Light:

Automobile Car Freight Elevator


Two gate Freight Elevator


5000kg warehouse cargo lift

Effective car transport nanny

Ceiling: Paint Steel

Car wall/Car door: Paint steel

Illumination: Energy-saving light

Door Opening Mode: Side opening

C.O.P: stainless steel hairline panel

Flooring: Checkered plate

Sill: Cast iron

Double operation panels

The elevator car has two operation boxes. Therefore the driver can operate the elevator without stepping out of his/her beloved car.

Signal display system

Special signal display system is convenient for both inside and outside drivers.

Opposite door configuration

The elevator car has front and rear opening. It is more convenient for the car to enter into/exit from the elevator car. And it is more secure too.

Products Specifications


Load(kg) Speed(m/s) Door opening type Net door opening(mm) Exterior size of car(mm) Hoistway net size(mm) Machine room net size(mm)
3000 0.25/0.5 Four panel center opening 2400*2200 2700*5800 Size(mm) Pit depth Top floor height 4100*6160*2500
5000 0.25/0.5 Four panel center opening 2600*2200 3500*7200 4100*6160 1600 4800 4750*7560*2500

Note: only for reference, final manufactures please follow contract.

· with/without drive operation · Door closing time auto delaying
· Automatic return to the base landing · False-call canceling
· Automatic landing · Emergency Light
· Call cancel when begin reverse-running · Driven over current protection
· Cage door opening when elevator arrives the floor where there is a hall call · Door opening / closing time-limited protection
· Door opening / closing call indication · Rope sliding protection
· Indication in the cage when hall calling · Door Nudging
· Self-Learning of shaft data · Trouble self-diagnosis and memory
· Full load non-stop operation · Over speed falling protection
· Overload alarm, Car Operating panel display: “OL” · Top/Bottom landing overpass protection
· Alarming device · Inspection Operation
· In-car and m/r inter talk device · Floor display
· Light and fan auto-control · Light curtain protection with mechanical safety edge
· Elevator Locking Device · Fireman’s return switch




Note: Reference only, for detail information, please contact SUNNY elevator.



Freight Elevator

5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate 1


5000kg Automobile Car Freight Elevator Warehouse Cargo Lift With Two Gate 2


1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
