Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell

Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell
Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell

Large Image :  Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Passenger Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 450-1600kg
Speed: 1.00 - 4.00m/s Car Wall: Mirror Etching Stainless Steell
Door Knife: Single Warranty: 12 Months After Shipping
Elevator Type: Passenger Elevator Material: Stainless Steel
Model: Passenger Elevator Type: Passenger Elevator
Highlight:

Passenger Freight Elevator

,

1600kg Freight Elevator

,

4.00m/s Passenger Freight Elevator

450-1600kg Passenger Panoramic Building Elevator & Shopping Mall



Small machine room passenger lift specifications
No. Of persons Rated capacity
(kg)
Rated speed (m/s) Car net size Door net size(DW*DH)mm Shaft inside dimension Machine room size Max traveling height(m)
W*D(mm) 2P center opening W*D(mm) Pit depth OH W*D*H(mm)
6 450 1.0 1200*1000 700*2100 1750*1620 1500 4400 1750*1620*2500 45
8 630 1.0 1400*1100 800*2100 2000*1720 1500 4400 2000*1720*2500 45
1.6/1.75 1600 4500 96
10 800 1.0 1400*1350 800*2100 2000*2000 1500 4400 2000*2000*2500 45
1.6/1.75 1600 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
13 1000 1.0 1600*1500 900*2100 2200*2150 1500 4400 2200*2150*2500 45
1.6/1.75 1600 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
3.0 2600 5600 150
3.5 3100 5950 180
4.0 3850 6350 180
15 1150 1.0 1700*1500 1000*2100 2300*2200 1500 4400 2300*2120*2500 45
1.6/1.75 1700 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
3.0 2600 5600 150
3.5 3100 5950 180
4.0 3850 6350 180
16 1250 1.0 1950*1400 1100*2100 2550*2100 1500 4400 2600*2100*2500 45
1.6/1.75 1700 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
3.0 2600 5600 150
3.5 3100 5950 180
4.0 3850 6350 180
18 1350 1.0 1950*1500 1100*2100 2550*2250 1500 4400 2600*2200*2500 45
1.6/1.75 1700 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
3.0 2600 5600 150
3.5 3100 5950 180
4.0 3850 6350 180
21 1600 1.0 1950*1750 1100*2100 2550*2500 1500 4400 2600*2500*2500 45
1.6/1.75 1700 4500 96
2.0 1800 4900 120
2.5 2000 5100 150
3.0 2600 5600 150
3.5 3100 5950 180
4.0 3850 6350 180



 Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell 0



Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell 1



Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell 2Single Door Passenger 4.00m/S 1600kg Passenger Elevator Mirror Etching Stainless Steell 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
