Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-SG-AQ32K
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $90~150
Packaging Details: Wooden box
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Pcs/ Month
Detailed Product Description
Name: Progressive Safety Gear Rated Speed: 0.63~2.0m/s
P+Q: 1200~2700kg Used: Passenger Elevator
Business Type: Manufacturer Warranty Time: 12 Months
Product Name: Elevator Parts Transportation: Sea Transportation
Model: Progressive Safety Gear Product: Progressive Safety Gear



Elevator Safety Components Progressive Safety Gear With GB And CE Certified


Product advantage: this product receives the signal from the speed limiter during the overspeed operation of the elevator out of
control, the belleville spring is used as the elastic element to provide acting force ofthe safety gear wedge to clamp the guide rail, and
to stop the uncontrolled elevator car.This productis provided with the compact structure and small volume because ofthe use ofthe
belleville spring as an elastic element, and the safety gear, which can be easily installed and operated, acts stably and reliably,and
can be used on the car side or the counterweight side.



Product description



Rated speed(m/s) Permitted P+Q(kg) Rail width(mm) Lubrication of Guide Rail Certifcation
0.63~2.0 1200~2700 9,10,15.88,16 Yes/No GB
0.5~2.0 1200~2700 9,10,16 Yes/No CE



Elevator Safety Components Progressive Safety Gear With GB And CE Certified 0



Elevator Safety Components Progressive Safety Gear With GB And CE Certified 1



Elevator Safety Components Progressive Safety Gear With GB And CE Certified 2



Elevator Safety Components Progressive Safety Gear With GB And CE Certified 3



Elevator Safety Components Progressive Safety Gear With GB And CE Certified 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
