RVS PVC Insulated Twisted Cable 2x0.5mm for Elevator Parts

Large Image : RVS PVC Insulated Twisted Cable 2x0.5mm for Elevator Parts

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	RVS

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$500~1200
Packaging Details:	container
Delivery Time:	15~30 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000 pcs/month

Contact Now

Detailed Product Description

Name:	Flexibility Twisted Cable	Specification:	2*0.5
Insulation Resistance At 70°C(Ω/KM):	≥0.016	Packing:	Wooden Box
Application:	Lift Parts	Transportation:	Sea Transportation
Transportation Mode:	EMS Or UPS) /LCL By Sea Or Train	Conductor Structure:	28/0.15
Model:	Flexibility Twisted Cable	Type:	Flexibility Twisted Cable
Product:	Flexibility Twisted Cable
Highlight:	PVC insulated twisted cable , elevator parts cable 2x0.5mm , elevator spare parts cable

High Flexibility RVS PVC Insulated Twisted Cable Without Sheath - Durable & Flexible Bare Copper Wire

Product Specifications

Attribute	Value
Name	Flexibility Twisted Cable
Specification	2*0.5
Insulation resistance at 70°C(Ω/KM)	≥0.016
Packing	Wooden box
Application	Lift Parts
Transportation	Sea Transportation
Transportation mode	EMS or UPS /LCL by sea or train
Conductor Structure	28/0.15
Model	Flexibility Twisted Cable
Type	Flexibility Twisted Cable
Product	Flexibility Twisted Cable

Product Description

High Flexibility Twisted Cable Without Sheath RVS PVC Insulated Wire

Applications

Applied for the internal connection of the cabin, machine room, and temporary connection in the shaft.

Key Features

PVC insulation
Rated voltage AC300/300V, rated temperature 70℃
The conductor consists of multi-copper wires or tinned copper wires are available

Cable Parameters

Type	Specification	Conductor Structure (quantity/diameter)	Finished product (max.outer dia.)(mm)	Insulation resistance at 70°C(Ω/KM)	DC resistance of conductor at 20℃ (Ω/KM)
RVS	2*0.5	28/0.15	6.0	≥0.016	≤39.0
RVS	2*0.75	42/0.15	6.2	≥0.014	≤26.0
RVS	2*1.0	57/0.15	6.6	≥0.011	≤19.5
RVS	2*1.5	84/0.15	7.2	≥0.010	≤13.3
RVS	2*2.5	140/0.15	8.2	≥0.009	≤7.98
RVS	2*4	224/0.15	9.2	≥0.007	≤4.95
RVS	2*6	189/0.2	10.6	≥0.006	≤3.30

Frequently Asked Questions

1. Are the elevator wire ropes durable?

The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won't break at the same time.

2. Is it dangerous for power failure suddenly during the elevator running?

If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure, elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.

3. Will us be hurt when it closed suddenly?

In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.

4. How the elevator running?

Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.

5. Is the escalator installation complicated?

We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.

6. Do you have any certifications?

Yes, we do with ISO9001 / CCC / CE Certificates for u.
