450-1000kg Load Maximize Building Space With A Machine Room Less Elevator

450-1000kg Load Maximize Building Space With A Machine Room Less Elevator

A machine roomless (MRL) elevator is a type of traction elevator that eliminates the need for a separate machine room, making it an efficient and space-saving solution for modern buildings. Unlike traditional elevators that require a dedicated machine room (typically located above the elevator shaft), MRL elevators integrate the motor and control system within the hoistway itself, usually at the top or side of the shaft.

Key Features of MRL Elevators:

1. Space Efficiency – By removing the need for a machine room, MRL elevators maximize usable building space, making them ideal for low- and mid-rise buildings where space is limited.

2. Energy Efficiency – Many MRL elevators use permanent magnet synchronous motors (PMSMs), which consume less power than traditional geared motors, reducing energy costs.

3. Quiet Operation – Modern MRL systems operate with minimal noise, enhancing passenger comfort.

4. Flexible Installation – Since the machinery is housed within the hoistway, MRL elevators can be installed in both new constructions and retrofit projects without major structural modifications.

5. Advanced Safety Features – MRL elevators comply with international safety standards, featuring emergency brakes, backup power options, and sophisticated control systems.

STANDARD FUNCTIONS

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
