380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl

Large Image : 380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	Machine Roomless Elevator

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$7000-12000
Packaging Details:	container
Delivery Time:	15~30 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	500 Set/ Year

Contact Now

Detailed Product Description

Name:	Machine Room Less Passenger Lift	Load:	450kg-1600kg
Speed:	0.5~2.5m/s	Persons:	6-21
Car Wall:	Mirro Stainless Steel And Hairline Stainless Steel	Foor:	PVC
Machine Room:	Without	Certification:	ISO, CE Certificate
Machine:	Gearless	Voltage:	380V/220V
Model:	Machine Room Less Passenger Lift	Type:	Machine Room Less Passenger Lift

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl

Load(kg)	Person	Speed(m/s)	Door Opening(mm)	Cabin Size(mm)	*Shaft Size(AHBH)**	Pit Depth	Head Room Height(mm)
450	5	0.50	700*2100	1150*1100	1700*1800	≥ 1500	≥ 3500
630	8	1.0-1.5	800*2100	1300*1250	1850*1900	≥ 1500	≥ 3500
800	10	1.0-1.75	800*2100	1500*1300	2050*1950	≥ 1500	≥ 3500
800	10	1.0-1.75	900*2100	1500*1300	2050*1950	≥ 1500	≥ 3500
1000	13	1.0-2.5	900*2100	1600*1500	2150*2150	≥ 1500	≥ 3500
1250	16	1.0-2.5	1000*2100	1750*1600	2300*2250	≥ 1500	≥ 3500
1600	21	1.0-2.5	1100*2100	2050*1700	2600*2450	≥ 1500	≥ 3500
We can also desgin according customer requirement for approved residential elevators

Basic Functions of Passenger Elevators
1	Full-automatic sorting operation	31	CAN communication fault protection
2	Door closing blocking automatic return function	32	Master CPU self-check protection
3	Overload alarm	33	Overheating protection of drive device
4	Straight operation at full load	34	Upward and downward running overspeed protection
5	Parallel operation	35	Contact detection protection of contactor
6	Directly stop operation	36	Leveling fine adjustment
7	Emergency electric driving of machine room	37	Car alarm
8	Re-initialize the operation	38	Stop switch
9	Automatic stop	39	Fire switch
10	Automatic leveling	40	Car roof overhaul
11	Automatic stop in case of fault	41	Exchange landing
12	Automatic elimination of reverse command	42	Power supply filtering function
13	Automatic return to base station in case of fire alarm	43	Speed feedback detection function
14	Automatic correction of floor location signal	44	Brake feedback detection function
15	Automatic control of lighting fan inside the lift car	45	Self-learning of shaft location
16	Unattended to automatically return to base station	46	Diagnosis of shaft self-learning failure
17	Overspeed protection	47	Elimination of false command
18	Low speed protection	48	Door opening/closing button
19	Ground protection	49	Fault self-diagnosis
20	Anti-slip protection	50	Tips for running direction outside the hall and the lift car
21	Light curtain protection of the door	51	Fault history record
22	Reverse operation protection	52	Arbitrary setting in the service layers
23	Terminal floor protection	53	Opening the door outside the hall of this floor
24	Overload protection of the motor	54	Setting of floor display character
25	Running timeout protection	55	Respectively control for the door of the hall and the lift car
26	Short-circuit protection of door lock	56	Outside door opening protection
27	Fault protection of door opening and closing	57	Digital hall/display in the lift car
28	Running door lock breakage protection	58	Emergency lighting in the car in case of power failure
29	Leveling switch fault protection	59	Five-way communication device
30	Delay protection of car door closing	60	Setting of floor display character

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl 0

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl 4

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl 5

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl 6

380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl 7

FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.

2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.

3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.

4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
