Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Panoramic Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Panoramic Elevator Load: 450~1600kg
OH: 4500 Speed: 0.2~0.4m/s
Elevator Door: Center Opening Door Deceleration Device: With Deceleration Device
Material: Stainless Steel Application: Passager Elevator
Model: Panoramic Elevator Type: Panoramic Elevator

Passenger Elevator Lift Observation Elevator Panoramic Elevators With Elevator Door Glass Sightseeing Elevator Lifts





Fine and exquisite observation elevator enhances building grade. It gighlights the whole building.
Observation elevator is a mobile scene. It has fine and exquisite visual aesthetics,perfect and comfortable travel. It applies modern new material and new fully computerized,vector type variable frequency speed regulation(VVVF) control technology. It combines with data netmork system,modular structure,the latest machining craft&technoligy.



Loading capacity Rated speed Door
open type
Door opening size(W x H)mm Car size (Ax B) mm Hoist way size(AH x BH) mm Machine room size
PIT OH (W x D x H)mm
450kg 1.0/1.5 /1.75 Center 800x2100 1400x850 2000x1550 1500/1600 4500 2500x3200x2500
630kg 1.0/1.5 /1.75 Center 800x2100 1400x1100 2000x1750 1500/1600 4500 2500x3600x2500
800kg 1.0/1.5 /1.75 Center 800x2100 1400x1350 2000x2000 1500/1600 4500 2500x3800x2600
1000kg 1.0/1.5 /1.75 Center 900x2100 1600x1400 2200x2150 1500/1600 4500 3000x4000x2600
1250kg 1.0/1.5 /1.75 Center 1100x2100 2000x1400 2600x2150 1500/1600 4500/4700 4000x4500x3000
1350kg 1.0/1.5 /1.75 Center 1100x2100 2000x1500 2600x2250 1500/1600 4500/4700 4000x4500x3000
1600kg 1.0/1.5 /1.75 Center 1100x2100 2000x1750 2600x2500 1500/1600 4500/4700 4000x4500x3000







Passenger Elevator Lift Observation Elevator Panoramic Elevators With Elevator Door Glass Sightseeing Elevator Lifts 0



Passenger Elevator Lift Observation Elevator Panoramic Elevators With Elevator Door Glass Sightseeing Elevator Lifts 1



Passenger Elevator Lift Observation Elevator Panoramic Elevators With Elevator Door Glass Sightseeing Elevator Lifts 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
