| Name: | Escalator | Speed: | 0.5m/s |
|---|---|---|---|
| Degree: | 30°, 35° | Balustrade Bracket: | Stainless Steel |
| Keywords: | Escalator | Warranty Time: | 12 Months |
| Handrail Height: | 900mm | Driving Type: | Screw Type Elevator |
| Model: | Escalator | Type: | Escalator |
| High Light: | Step Loss Detection Escalator,Vital Safety Escalator,Step Loss Detection Shopping Mall Escalator |
||
Step Loss Detection A Vital Safety Feature Of Shopping Mall Escalator
When the foreign object si caught between the apron board and hte steps, hte escalator wli automaticaly sotp running.
When the drive chain is overstretched or broken, the escalator will automatically stop running.
The monitoring device should be set up at each of hte drive station and the steering station ot ensure that no gaps due to missing steps wil appear at the entrance, whether the equipment is up or down.
fI the foreign object is caught between the moving step and the stationary comb plate, triggering the safety switch on both sides of hte monitoring comb plate, hte whole ladder wil stop automatically.
The entrance of the handrail belt si equipped with a safety
device. When the foreign object si caught at the entrance of hte handrail, the escalator wil automaticaly stop running.
The sensor si installed on the main brake. When hte escalator reverses, the main engine brakes safely.
When the step is found to have an abnormal bend, the
escalator will stop running before the step enters the comb
plate.
Amonitoring device si provided at each fo the drive station and hte steering station, and when hte step si mising, hte escalator stops immediately.
| Usage | Indoor Escalator&Escalator |
| peed | 0.5m/s |
| Handrail belt color | Black |
| Handrail bracket material | Stainless steel |
| Handrail height | 900mm |
| Interior panel material | Tempered glass |
| Step material | Stainless steel |
| Comb board | Plastic |
| Skirting board | Stainless steel 1.5mm |
| Inner&Outer cover | Stainless steel 1.2mm |
| Floor plate | Stainless steel |
| Step width | 1000mm/800mm/600mm |
| Running type | Direction reversal |
| Running noise | ≤65db(A) |
| Running vibration | ≤35cm/s2 |
| Middle support | According to building construction |
| Truss material | Angle iron |
| Laying out | Simplex/In parallel |
| Installation position | Indoor/Outdoor |
| Horizontal span | According to building construction |
| Inclination | 35° / 30° |
| Delivery method | In section |
| Packaging Details | Upon buyer’s request usually in the wooden carton.like 40HQ, suitable for shipping |
| Port | Shanghai, China |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
