Product Details:
Payment & Shipping Terms:
|
| Name: | Moving Walkway Sidewalk Walks | Step Width: | 800/1000mm |
|---|---|---|---|
| Power: | 8~11kw | Step: | Aluminium Alloy |
| Pallet Width: | 800/1000mm | Speed: | 0.5M/S |
| Specification: | CE; IS9001; IS14001 | Angle: | 0~6° |
| Product: | Moving Walkway Sidewalk Walks | Model: | Moving Walkway Sidewalk Walks |
| High Light: | 0.5m/S Indoor Moving Walkway,Outdoor Moving Walkway 1000mm,Aluminium Alloy Escalator Walkway |
||
1000mm 0.5m/S Outdoor Indoor Walks Moving Walkway With Innovative Solution
MOVING WALK
SUNNY moving walk brings a new simple and comfort shopping level for people. It creates an easy and safe access for people to every place of the building, even equipped with full goods.
Blending technology and fashion, globally recognized as escalator and moving walk specialist. This innovative solution is an asset to any high-quality shopping experience.
Moving walk puts safety in the first place in designing, passes strict test to ensure maximum safety.
lnstruction
1.When using temperature is less than 0° (outdoor or semi outdoor), heater should be increased.And consult manufacturerfor the totaT power of the heater.
2.There are sufficient smooth area in entrance and exit of moving walk and its width is at least distance of center line of handrail
and the depth from turning end of handrail is at least 25 m. if the width is twice longer than center distance of handrail, and itsdepth is allowed to be reduced by 2 m.
3.In case of pit, water-proof treatments should be done and handled by users.
4.The distance from automatic side ways to any barier is 2500, otherwise protection plate should be added to triangle place of handrailand floor and it should be handled by users.
5.Users provide power and grounding device less than 4 ohm of resistance,upper bearing beam and reserve 2 m of inlet
wire allowance.
6. lf middle support bearing beam adopts steel structure, consult manufacturer.7.The decoration of moving walk and field should be made by users.
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
