Product Details:
Payment & Shipping Terms:
|
| Name: | Moving Walkway Sidewalk Walks | Step Width: | 800/1000mm |
|---|---|---|---|
| Angle: | 30/35 Degree | Step: | Aluminium Alloy |
| Handtail Color: | Black, Red | Speed: | 0.5M/S |
| Specification: | CE; IS9001; IS14001 | Power Frequency: | 50Hz/60Hz |
| Product: | Moving Walkway Sidewalk Walks | Model: | Moving Walkway Sidewalk Walks |
| High Light: | Outdoor Moving Walkway 0.5m/S,Indoor Airport Moving Walkway,Sidewalk Walk 1000mm |
||
1000mm 0.5m/S Out Door Indoor Airport Moving Walkway Sidewalk Walks
| Step width(A) | Lift height(H) | Motor Power(KW) |
| 800 | 2500-3670 | 5.5 |
| 3671-4800 | 7.5 | |
| 4801-5100 | 8 | |
| 5101-6600 | 11 | |
| 6601-7500 | 13 | |
| 1000 | 2500-2950 | 5.5 |
| 2951-3900 | 7.5 | |
| 3901-4100 | 8 | |
| 4101-5490 | 11 | |
| 5491-6150 | 13 | |
| 6151-7000 | 15 | |
| 7001-7500 | 16 |
| Step width(A) | A | B | C | D | E | F |
| 800 | 800 | 1038 | 1400 | 2900 | 3550 | 1400 |
| 1000 | 1000 | 1238 | 1600 | 3300 | 3950 | 1600 |
| Step width(A) |
Intermediate support |
Supporting force R1 | Supporting force R2 | Supporting force R3 | Supporting force R4 |
| 800 | 0 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | / | / |
| 1 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | R3=0.00507*L*2 | / | |
| 2 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | R3=0.00507*(L+L)*2 | R4=0.00507*(L+L)*2 | |
| 1000 | 0 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | / | / |
| 1 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | R3=0.00585*L*2 | / | |
| 2 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | R3=0.00585*(L+L)*2 | R4=0.00 |
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
