Product Details:
Payment & Shipping Terms:
|
| Name: | Automobile Elevator | Load: | 3000~5000kg |
|---|---|---|---|
| Feature: | Large Space | Speed: | 0.25~0.5m/S |
| Model: | Car Lift Elevator | Pit Depth: | 1800mm |
| Type: | Automobile Elevator | Material: | Stainless Steel |
| Product: | Automobile Elevator | ||
| High Light: | Stainless Steel Automobile Elevator,Automobile Elevator 5000kg,Car Parking Elevator 0.5m/S |
||
Elevator Specifications 5000kg Stainless Steel Automobile Elevator For Sale
Car Elevator Introduction
With the development of economy,people's lives are improving constantly and cars are gradually emerging in the common households. The automobile elevators developed by SUNNY elevator,fully employ the years of expertise of German in manufacturing automobile elevators. The elevators are developed with an account of the domestic market situation and by means of employing highly matured VF technology to realize precise speed control,which avoids the noise and vibration of the cabins caused by increased load of the traction system due to the uneven force on the cabin and best optimizes the characteristics of this product series,making it safer and more reliable for the entry of cars.
1.Automobile Elevator Specifications
| Loading capacity (kg) |
Speed (m/s) | Entrance (JJ X HH)mm | Door open type | Car net size | Shaft inside dimension(mm) | Machine room size(mm) | ||
| (AA X BB)mm | (AH X BH)mm | PP | OH | (W X D X H)mm | ||||
| 3000 | 0.5 | 2400 X 2400 | Center opening double-folded type | 2670 X 6000 | 4300 X 6360 | 1700 | 5000 | 4500 X 7000 X3000 |
| 5000 | 0.25 | 2800 X 2400 | Center opening double-folded type | 3500 X 7200 | 4800 X 7560 | 1700 | 5200 | 5000 X 8500 X 3000 |
2. Car Size Inside Reference
| Capacity load(kg) | Car net size inside (m2) |
| 3000 | ≤15 |
| 4000 | ≤20 |
| 5000 | ≤25 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
