0.4m/S Kitchen Meals Food Dumbwaiter Elevator 100- 500kg Load

0.4m/S Kitchen Meals Food Dumbwaiter Elevator 100- 500kg Load
0.4m/S Kitchen Meals Food Dumbwaiter Elevator 100- 500kg Load

Large Image :  0.4m/S Kitchen Meals Food Dumbwaiter Elevator 100- 500kg Load

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Durable Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3000~7000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Load: 100~500kg Name: Dumbwaiter Lift
Speed: 0.4m/s Type: Durable
Material: Stainless Steel Warranty: 12 Months
Usage: Dumbwaiter Lift Keywords: Dumbwaiter Lift
Model: Dumbwaiter Lift Product: Dumbwaiter Lift
High Light:

Kitchen Meals Food Dumbwaiter Elevator

,

Dumbwaiter Elevator 0.4m/S

,

500kg Load Dumbwaiter Lift



Easy To Use Kitchen Meals Food Dumbwaiter Elevator With High Quality Export Wooden Case



*Easy to installation and fitment
*with or not shaft and machine room can be optional
*GB25194-2010 standard
*Special elevator traction and guide rail
*cabin , landing doors , frame are hairline stainless steel
*Mircomputer , PLC, VVVF control
*G floor lock , electrical door lock , landing door lock ,
*Voice notice , door closed notice
* Floor number , and running arrow shows



Product Parameters
NO Capa
city
(kg)
motor power
(w)
Volt
age
(v)

speed
(m/s)
Cabin Size Shaft size Overhead work bech height pit buffer distance
H(mm) ≥(mm) ≥(mm) Q(mm) H(mm)
width depth Height width depth floor type work bech type P(mm) stright
open
side open revolve Normal with car door
1 100 1.1 380 0.4 600 600 800 1200 900 / 3000 700 / / / 500 700
2 100 1.1 380 0.4 600 600 800 1200 1100 / 3000 700 / / / 500 700
3 100 1.1 380 0.4 800 800 800 1400 1100 / 3000 700 / / / 500 800
4 200 1.5 380 0.4 800 800 800 1400 1100 / 3000 700 / / / 500 700
5 200 1.5 380 0.4 800 800 1000 1400 1100 3000 / / 700 250 250 600 800
6 200 1.5 380 0.4 800 1000 1000 1400 1300 3000 / / 700 250 250 600 800
7 200 1.5 380 0.4 1000 1000 1000 1600 1300 3000 / // 700 250 250 600 800
8 250 2.5 380 0.4 800 1000 1200 1400 1300 3200 / / 1000 250 250 800 1000
9 300 3.0 380 0.4 1000 1000 1200 1600 1300 3200 / / 1000 250 250 1000 1200
10 500 5.5 380 0.4 1000 1000 100 1600 1300 3500 / / 1200 250 250 1000 1200





0.4m/S Kitchen Meals Food Dumbwaiter Elevator 100- 500kg Load 0



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
