Product Details:
Payment & Shipping Terms:
|
Name: | Sidewalk Moving Walkway | Width: | 800~1400mm |
---|---|---|---|
Angle: | 0-12 Degree | Keywords: | Pallet Walkway |
Motor Power: | 380V/50Hz/3p | Speed: | 0.5M/S |
Specification: | CE; IS9001; IS14001 | Span Length: | ≤105000mm |
Product: | Sidewalk Moving Walkway | Model: | Sidewalk Moving Walkway |
Highlight: | Sidewalk Moving Walkway Safety Line,380V Moving Walkway,Pallet Moving Sidewalk |
380V Power Supply Power With Sidewalk Moving Walkway Safety Line
A Sidewalk Moving Walkway is an innovative pedestrian transportation system designed to move people efficiently over longer distances, often used in outdoor or semi-outdoor environments such as urban sidewalks, parks, tourist attractions, and large industrial complexes. Unlike traditional indoor moving walkways, these systems are built to withstand outdoor conditions, including exposure to weather, temperature fluctuations, and heavy usage.
Constructed with durable materials such as weather-resistant metals, reinforced composites, and UV-stable plastics, Sidewalk Moving Walkways are engineered for longevity and minimal maintenance. The walkway typically features a continuous belt or pallet system powered by an electric motor, providing a smooth and reliable ride. The speed is adjustable, usually ranging from a slow walking pace to a faster jogging speed, catering to diverse user needs.
Safety is a top priority, with features such as non-slip surfaces, synchronized moving handrails, and sensors to detect obstructions or malfunctions. The walkway may also include drainage systems to handle rainwater and built-in heating elements to prevent ice formation in colder climates.
Sidewalk Moving Walkways enhance accessibility, reduce pedestrian congestion, and improve mobility in areas with high foot traffic. They are particularly beneficial for elderly individuals, people with disabilities, and those carrying heavy luggage. By combining functionality, durability, and safety, these walkways represent a modern solution for urban mobility and public convenience.
Moving walk | Moving walkway, travelator, passenger conveyor, sidewalk, autowalk, walker |
Span Length | L≤105000mm |
Step Width | 800mm, 1000mm, 1200mm, 1400mm |
Inclined Degree | 0°, 10°, 11°, 12° |
Speed | 0.5m/s, 0.65m/s |
Noise | ≤65dB |
Vibration | ≤35cm/s² |
Running | Single speed up &down reversible |
Delivery | 40ft high container |
Power Supply | Power 380V , 50Hz 3 Phase Five |
Lighting 220V, single phase | |
Energy Saving Function | VVVF, Auto start stop |
Functions
Standard safety functions | |||||
1 | Emergency Stop Button | Yes | 19 | Machine Room Protect Board | Yes |
2 | Handrail Entry Contact | Yes | 20 | Step Light | Yes |
3 | Broken Step Chain Protection | Yes | 21 | Skirt Panel Contact | Yes |
4 | Comb Plate Contact | Yes | 22 | Step Yellow Safety Line | Yes |
5 | Inspection Socket | Yes | 23 | Alarm Bell When Start | Yes |
6 | Phase Failure and Phase Stagger Protection | Yes | 24 | Floor Plate Open Device | Yes |
7 | Step Sag Contact | Yes | 25 | Alarm Signs | Yes |
8 | Stop Button | Yes | 26 | Main Driving Chain Broken Protect Device | Yes |
9 | Main Power Switch | Yes | 27 | Overspeed Lowspeed Protection | Yes |
10 | Circuit Grounding Device | Yes | 28 | Step Static-free Device | Yes |
11 | Non-operational Reversal Safety Device | Yes | 29 | Handrail Belt Speed Detect Protection | Yes |
12 | Overload Protect | Yes | 30 | Floor Plate Open Detect Device | Yes |
13 | Portable Lamp and Socket | Yes | 31 | Step Missing Detect Protection | Yes |
14 | Handrail Belt Antistatic Device | Yes | 32 | Working Brake Open Detect Device | Yes |
15 | Traction Flywheel Cover Open Detect Switch | Yes | 33 | Skirt Panel Anti Clamp Device | Yes |
16 | Maintenance Power Supply Socket | Yes | 34 | Working Brake | Yes |
17 | Step Anti Bounce Device | Yes | 35 | Auto Lubricating Device | Yes |
18 | Safety Signs | Yes | |||
Optional functions | |||||
1 | Blocking device | ○ | 8 | Handrail lightening | ○ |
2 | Anti-climb device | ○ | 9 | Direction indicator | ○ |
3 | Anti-climb device is Not preset. | Yes/No | 10 | Oil-water separator | ○ |
4 | Vertical protect board | ○ | 11 | Liquid level switch | ○ |
5 | Handrail disconnect protect device | ○ | 12 | Heating device | ○ |
6 | Brake shoe wearing detection | ○ | 13 | Cladding | ○ |
7 | Auxiliary brake | ○ |
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
