0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator

0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator

Large Image :  0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: 35° Escalator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Escalator Speed: 0.5m/s
Step Width: 600~1000mm Inclination: 30/35°
Used: Indoor/Outdoor/Semi-Outer Warranty: 12 Months
Usage: Shopping Mall Product Name: Escalator
Model: Shopping Mall Escalator Type: Shopping Mall Escalator
Product: Shopping Mall Escalator Drive Type: VVVF
Highlight:

Shopping Mall Electric Escalator

,

0.5m/S Outdoor Escalator

,

30 Degree Shopping Mall Passenger Escalator

Durable Outdoor Escalators Electric Escalator With Competitive Escalator Price



The Durable Outdoor Escalators Electric Escalator is a robust and reliable vertical transportation solution designed to withstand harsh environmental conditions while providing efficient and safe movement for pedestrians in outdoor settings. These escalators are commonly used in locations such as shopping malls, stadiums, airports, and public transportation hubs, where they are exposed to weather elements like rain, wind, dust, and temperature fluctuations.

Constructed with high-quality, weather-resistant materials, the outdoor escalator is built to endure corrosion, UV exposure, and mechanical stress. Key components, such as the steps, handrails, and structural framework, are made from durable stainless steel or galvanized steel, ensuring long-term performance and minimal maintenance requirements. The escalator is also equipped with advanced drainage systems to prevent water accumulation, which could otherwise lead to operational issues or safety hazards.

Safety is a top priority in the design of these escalators. They feature anti-slip steps, robust handrails, and emergency stop buttons to ensure passenger safety. Additionally, the escalator is equipped with weatherproof covers and heating systems to prevent ice formation in colder climates, ensuring reliable operation year-round.

The electric drive system of the outdoor escalator is energy-efficient, utilizing advanced motor technology to reduce power consumption while maintaining smooth and quiet operation. Its modular design allows for easy installation, maintenance, and repair, minimizing downtime.

Overall, the Durable Outdoor Escalators Electric Escalator combines durability, safety, and efficiency, making it an ideal solution for high-traffic outdoor environments where reliable and continuous pedestrian movement is essential.



Escalator Indoor and Outdoor
Travel Height H≤30000mm
Step Width 600mm, 800mm, 1000mm
Inclined Degree 35°, 30°
Speed 0.5m/s, 0.65m/s
Escalator Width 1200mm, 1400mm, 1600mm
Noise ≤65dB
Vibration ≤35cm/s²
Flat step 2 flat step, 3 flat step, 4 flat step
Running Single speed up &down reversible
Delivery 40ft high container
Power Supply Power 380V , 50Hz 3 Phase 5 Line
Lighting 220V, single phase
Energy Saving Function VVVF, Auto start stop



0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 0



0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 1



0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 2



0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 30.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 4



0.5m/S Electric Shopping Mall Escalator 30 / 35 vDegree Outdoor Escalator 5



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
