Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator

Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator
Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator

Large Image :  Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 630~1600kg
Speed: 1.0~1.75m/s Handrail: Stainless Steel/wooden/others
Warranty: 12 Months After Shipping Application: Office Building
Usage: Passenger Elevator Drive Type: AC
Product: Passenger Elevator Model: Passenger Elevator
High Light:

Office Building Passenger Elevator Lift

,

1.0m/s Passenger Elevator Lift

,

AC Drive Hydraulic Passenger Lift

Standard Passenger Elevator Lift For Office Building With Automatic Rescue Device Elevator

With Motor room
DL V CW CD CH OP OPH HW(mm) HD(mm) S K
(kg) (m/s) (mm) (mm) (mm) (mm) (mm) Min Min (mm) (mm)
630 1               1400 4300
1.5 1400 1100 2500 800 2100 1850 1750 1500 4500
1.75               1500 4550
800 1               1400 4300
1.5 1400 1350 2500 900 2100 1960 2000 1500 4500
1.75               1500 4550
1000 1               1400 4300
1.5 1600 1400 2500 900 2100 2050 2050 1500 4500
1.75               1500 4550
1150 1.0               1550 4450
1.5 2000 1350 2500 1100 2100 2500 2000 1650 4600
1.75               1650 4650
1350 1.0               1550 4450
1.5 2000 1500 2500 1100 2100 2500 2200 1650 4600
1.75               1650 4650
1600 1.0               1550 4450
1.5 2000 1700 2500 1100 2100 2500 2400 1650 4600
1.75               1650 4650





Without Motor room

DL V CW CD CH OP OPH HW(mm) HD(mm) Min S Min K
(kg) (m/s) (mm) (mm) (mm) (mm) (mm) Min Min (mm) (mm)
630 1 1100 1400 2500 700   1900 1800 1600 4250
1.5 2100 1700 4400
1.75   1700 4500
800 1 1350 1400   900   2250 1800 1600 4250
1.5 2500 2100 1700 4400
1.75     1700 4500
1000 1 1600 1400   900   2400 1800 1600 4250
1.5 2500 2100 1700 4400
1.75     1700 4500
1150 1 1800 1500   1000 (CO)   2700 2000 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700
1150 1 1200 2200   1000 (SO)   2050 2650 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700
1350 1 2000 1500   1100 (CO)   2850 2000 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700
1350 1 1300 2300   1100 (SO)   2150 2800 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700
1600 1 2000 1700   1100 (CO)   2850 2100 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700
1600 1 1400 2400   1200 SO)   2250 2900 1600 4550
1.5 2500 2100 1700 4650
1.75     1700 4700

Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator 0


Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator 1



Office Building Passenger Elevator Lift With Automatic Rescue Device Elevator 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
