Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building

Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building
Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building

Large Image :  Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 600-1600kg
Speed: 1.0m/s Handrail: Stainless Steel/wooden/others
Warranty: 12 Months After Shipping Application: Office Building
Usage: Passenger Elevator Drive Type: AC
Product: Passenger Elevator Model: Passenger Elevator
Highlight:

6 Person Passenger Elevator

,

Stainless Steel 304 Passenger Lift

,

Office Building Passenger Elevator 1.0m/s

Mirror Etched Stainless Steel Shop Passenger Manufacturer Elevator

Passenger Elevator With Machine Room
We can make 1.0--7.0m/s speed elevator.



Load (Kg)

Speed

(m/s)

Car Size

(mm)
Door Size (mm)

Shaft Size

(mm)
Overhead Size (mm)
Pit Size (mm)
600
1.0
1400*1100
800*2100
1900*1850
≥4200
≥1400
800
1.0
1400*1350
800*2100
1900*2000
≥4200
≥1400
1000
1.0
1600*1400
900*2100
2100*2050
≥4200
≥1400
1150
1.0
1800*1400
1000*2100
2300*2100
≥4200
≥1400
1250
1.0
1850*1500
1000*2100
2300*2250
≥4200
≥1400
1350
1.0
2000*1500
1100*2100
2500*2250
≥4200
≥1400
1600
1.0
2000*1750
1100*2100
2550*2550
≥4200
≥1400



Passenger Elevator Without Machine Room

We can make 1.0--7.0m/s,speed elevator.


Load (Kg)

Speed

(m/s)
Car Size (mm)
Door Size (mm)
Shaft Size (mm)
Overhead Size (mm)
Pit Size (mm)
600
1.0
1100*1400
800*2100
2000*1850
≥4400
≥1700
800
1.0
1350*1400
800*2100
2200*2050
≥4300
≥1700
1000
1.0
1400*1600
900*2100
2250*2150
≥4300
≥1700
1150
1.0
1400*1800
1000*2100
2450*2300
≥4300
≥1700
1250
1.0
1500*1800
1000*2100
2500*2300
≥4400
≥1800
1350
1.0
1500*2000
1100*2100
2650*2450
≥4400
≥1800



Parameter


Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building 0

Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building 1


Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building 2



Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building 3



Stainless Steel 304 Passenger Elevator 6 Person Passenger Lift For Office Building 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
