Large Image :  0.5m/s Factory Indoor Outdoor Escalator Safety Commercial

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: 35° Escalator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Escalator Speed: 0.5m/s
Degree: 30°, 35° Balustrade Bracket: Stainless Steel
Keywords: Escalator Warranty Time: 12 Months
Driven Type: AC Width Of Stair: 600~1000mm
Model: Escalator Product: Escalator
High Light:

Factory Indoor Escalator

,

Outdoor Commercial Escalator 0.5m/s

,

Commercial Shopping Mall Escalator

Escalator Indoor And Outdoor Escalator Factory Escalator Safety Commercial



Commercial type escalator is based on national standard GB16899-2011 international standard EN115 fully applied escalator industry advanced technology design and manufacturing. Adopts advanced microcomputer control system, high strength of truss structure, perfect protection, make safety, reliability and comfort product. Escalators fully satisfy the requirement of market, modern industry, hospital, hotel, CBD, services and large shopping center.



Specifications:

Rise: <=8000mm
Inclination: 30︒/35︒
Rated speed: 0.5m/s
Step width: 1000/800/600mm
Main configuration:
Controller: Micro control
Truss: Deflection 1/750(1/1000, 1/1500)
Machine: Turbo-worm/ Helical gear
Chain: Roller inside
Step: St. steel/ Aluminum alloy
Roller: Polyurethane
Main drive: Big friction wheel
Side panel: Overall welding
Track system: Profile rail
Handrail: C type
Handrail guide rail: St. steel/ Aulminum ally
Balustrade: Toughened glass/ St. steel
Skirt panel/Decking: St. steel
Lubrication system: Electromagnetic pump/Gear pump
Handrail entry: Aluminum alloy
Floor plate: St. steel/Aluminum alloy
Comb: Aluminum alloy/Engineering plastics





0.5m/s Factory Indoor Outdoor Escalator Safety Commercial 0

0.5m/s Factory Indoor Outdoor Escalator Safety Commercial 1

Delivery


 0.5m/s Factory Indoor Outdoor Escalator Safety Commercial 2



0.5m/s Factory Indoor Outdoor Escalator Safety Commercial 3



0.5m/s Factory Indoor Outdoor Escalator Safety Commercial 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
