200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry

200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry
200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry

Large Image :  200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Dumbwaiter Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $3000~7000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Dumbwaiter Elevator Business Type: Manufacturer
Load: 100-200kg Speed: 0.4m/s
Door Knife: Single Attendant: Without Attendant
Elevator Door: Sider Door Usage: Dumbwaiter Elevator
Model: Dumbwaiter Elevator
High Light:

Laundry Electric Dumbwaiter Elevator

,

Restaurant Electric Dumbwaiter Elevator

,

200kg Dumbwaiter Elevator For Home

200kg Electric Household Home Residential Restaurant Kitchen Basement Laundry Elevator Service Dumbwaiter Lift





Dumbwaiter Elevator and Service Lift

Our dumbwaiters for kitchens are usually made of stainless steel, so they are not affected by steam, hot food, water, etc. Hospitals and departmental stores also need our products to carry stores to different levels in the building. Only about a small space is required in the building to fit our dumbwaiter. Only one wall is required to support the smaller ones. We offer both traction and hydraulic dumbwaiter elevators, giving our customers more options. Available in varied types, sizes and other specifications, these dumbwaiters are subject to customization at the exact equipment for customers.



Load Speed Car size Door opening Hoistway size Machine room size
kg m/s W D OP OPH HW HD K(MR) K(MRL) mm
100 0.4 750 750 700 1000 1200 900 3600 4800 2000*2000*1800
200 0.4 1000 1000 950 1200 1450 1150 3000 4200







Dumbwaiter Elevator Construction Layout Diagram

200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry 0

200kg Electric Dumbwaiter Elevator For Restaurant Kitchen Basement Laundry 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
