|Degree:||35°||Type Of Work:||Middle-Level|
|Keywords:||Shopping Mall Escalator||Warranty Time:||12 Months|
|Driven Type:||AC||Running Mode:||Moving|
|Model:||Shopping Mall Escalator||Product:||Shopping Mall Escalator|
30 Degree modern Mall Escalator,
30 Degree parallel Mall Escalator,
30 Degree VVVF Mall Escalator
35 Degree Auto Start Indoor Escalator For Commercial Building With Auto Start
Safety Modern Parallel VVVF Shopping Mall Escalator
Application: Indoor use escalator With 35°
1. Fine energy-saving escalator
2. VVVF controll system
3. European standard with CE, ISO9001, ISO14001.
4. Superior properties
Modern-designed and safe escalator
1. Super-consciousness aesthetic design meets the characteristics of human physiology;
2. Humanized design, comfort and natural;
3. Advanced control system and driving device, superior driving system, superior driving chain, excellent workmanship assures the comfortable operation;
4. The safety protection functions as many as 21 items fully comply with national and European standard;
5. Automantic lubrication system lubricates all kinds of driving components, which prolongs products' operation life greatly.
6. Micro-computer controlled system performs with rapid calculation speed, high reliable moving, and also with failure code fixed, easy to be maintained;
7. Drive device arranged vertically assures enough space and convinience for maintenance.
8. Safety protection functions as many as 21 items fully comply with national and European standard.
|Traveling height(m)||≤ 7.2(6)|
|Horizontal steps||2/2, 3/3( Only for 30° )|
|Capacity (per. /h||4500/6750/9000|
|Handrail bracket||Stainless steel|
|Inner & outer decking||Hairline St. St.|
|Skirting||Wear resistant coating steel sheet|
|Landing plate||Stainless steel (anti-sliding)|
|llumination||lighting under upper & lower landing steps|
|Indicator||Failure code indicator on control cabinet|
Escalator Construction Sketch
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
