Product Details:
Payment & Shipping Terms:
|
| Name: | Home Elevator | Load: | 250-450kg |
|---|---|---|---|
| Speed: | 0.4m/s | Handrail: | Stainless Steel/wooden/others |
| Warranty: | 12 Months After Shipping | Application: | Office Building |
| Floor: | PVC | Control: | VVVF Elevator Control System |
| Product Name: | Home Elevator | Product: | Home Elevator |
| Type: | Home Elevator | ||
| High Light: | Villa 400kg Home Elevators,vertical 400kg Residential Elevators,1.75m speed Residential Home Elevators |
||
0.4m/S Lifts Elevator Home China Manufacturer Villa Elevator
1.75m Villa Speed Vertical 400kg Residential Home Elevator VVVF Elevator Control System
Home Elevator
Hydraulic or Traction type
Capacity (kg): 250, 320, 400, 450kg
Speed (m/s): 0.4m/s
Home Elevator Cabin
Decorative type cabin or hairline stainless steel, according to clients' requirements
Manual opening door or auto opening door
| Model&Type: | Customized |
| Power capacity: | According to the design |
| Decoration style: | Customized |
| Ceiling: | Hairline/Mirror/Titanium stainless frame, Powder spraying,LED lamp ect. |
| Car wall: | Hairline/Mirror/Titanium/etching stainless,crystal lighting,titanium gold,rose gold,art glass,Red shadow wood veneer,ebony,fillet |
| Floor: | PVC/Marble |
| Persons: | 3/4/5 |
| Rate capacity: | 250/320/400Kg |
| Rate Speed: | 0.4m/S |
| Floor Station: | Customized |
| Size: | 800*900/900*1100/1000*1200mm |
| Floor Hight: | Customized |
| Width of doorway: | Customized |
| Door opening width: | Customized |
| Door opening height: | Customized |
| Door Opening Forms: | A, Center opening door B, Side opening door C, Manually operated door |
| Hoistway size: | 1450*1000/1550*1300/1650*1400mm/Customized |
| OH: | 2700mm/3200mm/customized |
| PD: | 500mm/150mm/customized |
| Noise | <10db |
Construction Sketch
STANDARD CONFIGURATION
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
