Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S

Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S
Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S

Large Image :  Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Feature: Compact Structure Pit Depth: 1400mm
Name: Small Machine Room Elevator Load: 450~1350kg
Speed: 1.0~2.0m/S Overhead: 4200mm
Drive Type: AC Material: Stainless Steel 304
Control System: VVVF Elevator Control System Traction Machine: Gearless Or Gear Machine
Model: Small Passenger Lift Product: Small Passenger Lift
High Light:

small passenger lift

,

high speed elevator

,

Room Passenger Elevator 1.0m/S

Small Machine Room Passenger Elevator with Compactdesign and Energy Saving

Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S



Feature: Compact Structure
Name: Small Machine Room Elevator
Speed: 1.0~2.0m/S
Pit Depth: 1400mm
Load: 450~1350kg
Overhead: 4200mm


Space-creating fulfills great splendors
Small machine room passenger elevator inherited the modern highly sophisticated technology,based on the improved elevator system reliability and flexibility to achieve a truly environmentally and energy-saving adbantages.
Small machine room passenger elevator is compared with the usual machine room, with a reasonable layout construction, making room area as large as the hoistwang reaches saves floor space, while reducing the apperaance of the engine room of the building-specific effects on the appearance. It can be adapted to the requirements of a particular building construction matter, not only reduces the cost of construction, but also help to stimulate architects inspired to create blocks of magnificent works of art.
Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S 0
Compact design
Small machine room passenger elevator is a kind of elevator with new concept, which is for improving the construction value. The area of machine room can be reduced by more than 50% than traditional elevator, so it saved construction space and increased useful space.
Energy saving
Small machine room passenger elevator use permanent magnetic synchronous gearless traction machine, featuring high effective and energy saving.It save by 33% energy than the gear traction machine for the same capacity. The best design comprising special designed control cabinet with samll size and the most advanced with lower loss makes the layout of the machine room perfect.

Passenger Load Speed Car size Door size Shaft Pit depth Overhead height Stops Rise
kg m/s WxDxH(mm) WxH(mm) WxD(mm) P(mm) K(mm) Station HQ(m)
6 450 1.0 1100x1200x2400 700x2100 1900x1900 1400 4200 20 50
8 630 1.0 1100x1400x2400 800x2100 1950x1950 1600 4200 20 50
1.5 1100x1400x2400 800x2100 1950x1950 1600 4400 25 70
1.75 1100x1400x2400 800x2100 1950x1950 1650 4400 30 90
10 800 1.0 1400x1350x2400 800x2100 1950x2000 1400 4200 20 50
1.5 1400x1350x2400 800x2100 1950x2000 1600 4400 25 70
1.75 1400x1350x2400 800x2100 1950x2000 1600 4400 30 90
2.0 1400x1350x2400 800x2100 1950x2000 1650 4650 35 105
13 1000 1.0 1600x1500x2400 900x2100 2200x2150 1400 4200 20 50
1.5 1600x1500x2400 900x2100 2200x2150 1600 4400 25 70
1.75 1600x1500x2400 900x2100 2200x2150 1600 4400 30 90
2.0 1600x1500x2500 900x2100 2200x2150 1650 4650 35 105
16 1350 1.0 1950x1500x2500 1100x2100 1100x2100 1500 4200 20 50
1.5 1950x1500x2500 1100x2100 1100x2100 1600 4400 25 70
1.75 1950x1500x2500 1100x2100 1100x2100 1700 4400 30 90
2.0 1950x1500x2500 1100x2100 1100x2100 1750 4650 35 105


Small Machine Room Passenger Elevator Construction Layout Drawing
Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S 1

Compact Small Machine Room Elevator , Small Passenger Lift 1.0m/S 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
