Steel Belt Type Gearless Traction Machine with Elevator Spare Parts

Steel Belt Type Gearless Traction Machine with Elevator Spare Parts
Steel Belt Type Gearless Traction Machine with Elevator Spare Parts Steel Belt Type Gearless Traction Machine with Elevator Spare Parts

Large Image :  Steel Belt Type Gearless Traction Machine with Elevator Spare Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-MDT92
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $500~1200
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month
Detailed Product Description
Name: Gearless Traction Machine Load: 450~630kg
Poles: 24 Brake Voltage: DC110V/2.3A
Weight: 180kg Category: Elevator Parts
Warranty Time: 12 Months Transportation: Sea Transportation
Material: 304 Stainless Steel Or Customizable Application: Lift Parts
Model: Gearless Traction Machine Type: Gearless Traction Machine
High Light:

passenger lift parts

,

elevator car parts

Load 450~630kg Permanent Magnet Synchronous Steel Belt Type Gearless Traction Machine



Load range 450~630kg
Speed range 0.5~1.75m/s
Static load 2000kg
Sheave Φ325mm
Rating S5-40%ED
Net weight 180kg
Encoder ERN1387
Brake torque 2x325Nm
Brake power 352W
Brake voltage DC110V/2*1.6A
INS.CLASS F
Poles 24
IP code IP41



Traction Sheave Ropes
ΦD F Φ min-max Pitch
mm mm mm mm
325 72 8 4-5 12





Roping Load Speed

Sheave

Diam

Torque Power Freq. RPM

AC220V

Current

AC380V

Current

Sheave
kg m/s mm Nm kw Hz RPM A A
2:1 450 0.5 325 244 1.5 11.8 59 7.5 7.5 325-4-8-12
0.63 1.9 14.8 74 10.9 7.5
1.0 3.0 23.5 118 14.6 7.5
1.5 4.5 35.3 176 none 10.9
1.6 4.8 37.6 188 14.6
1.75 5.3 41.1 206 14.6
550 0.5 298 1.8 11.8 59 9.2 9.2 325-5-8-12
0.63 2.3 14.8 74 13.3 9.2
1.0 3.7 23.5 118 17.9 9.2
1.5 5.5 35.3 176 none 13.3
1.6 5.9 37.6 188 17.9
1.75 6.4 41.1 206 17.9
630 0.5 342 2.1 11.8 59 10.5 10.5 325-5-8-12
0.63 2.6 14.8 74 15.2 10.5
1.0 4.2 23.5 118 20.5 10.5
1.5 6.3 35.3 176 none 15.2
1.6 6.7 37.6 188 20.5
1.75 7.4 41.1 206 /



DIMENSION DRAWING

Steel Belt Type Gearless Traction Machine with Elevator Spare Parts 0



Steel Belt Type Gearless Traction Machine with Elevator Spare Parts 1



Steel Belt Type Gearless Traction Machine with Elevator Spare Parts 2



Steel Belt Type Gearless Traction Machine with Elevator Spare Parts 3



Steel Belt Type Gearless Traction Machine with Elevator Spare Parts 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
