Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized

Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized
Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized

Large Image :  Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Escalaror
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Shopping Mall Escalator Speed: 0.5m/s
Step Width: 1000mm Keywords: Shopping Mall Escalator
Warranty Time: 12 Months Angle: 30
Usage: Shopping Mall Drive Type: AC
Item Name: Shopping Mall Escalator Traveling Height: 3000-9000mm
Highlight:

commercial escalator

,

moving walk escalator

Indoor Escalator with Vvvf Control Safety Escalator with 30 Degree 1000mm Step Width



Escalators efficiently move large numbers of people with minimum waiting time. However, they operate constantly regardless of the number of passengers they carry. Therefore, even a small decrease in energy consumption produces substantial savings. We have made a number of improvements to the drive mechanism in its easy-to-maintain top machine room, which has been proven superior over many years of experience. An approximate 25% reduction in energy consumption has been achieved by enhancing drive transmission efficiency and reducing friction.



Motor capacity(KW)

Traveling height(ladder width)

1000



Traveling height(ladder width)

800



Traveling height(ladder width)

600


1000~3300 5.5 1000~3500 5.5 1000~3700 5.5
3400~4500 7.5 3600~4700 7.5 3800~4900 7.5
4600~4900 8 4800~5100 8 5000~5200 8
5000~5900 11 5200~5900 11 5300~5900 11
1000 1000 1158 1238 1600 1660 2310
800 800 968 1038 1400 1460 2110
600 600 758 838 1200 1260 1910
Step width A B C D E F
Model Traveling height(mm)

Net Weight

KN

capacity Transporation demension

R1

KN

R2

KN

h I

FHE(600)-30

(3600person/h)

Speed:0.5m/s

3000 57 46 41 2750 10900
3500 60 49 44 2780 11890
4000 64 52 47 2810 12880
4500 66 56 50 2830 13870
5000 71 59 53 2840 14860
5500 75 62 56 2860 15860
6000 79 65 59 2870 16860

FHE(800)-30

(4800person/h)

Speed:0.5m/s

3000 59 52 47 2750 10900
3500 63 56 50 2780 11890
4000 67 60 54 2810 12880
4500 71 64 57 2830 13870
5000 74 68 60 2840 14860
5500 82 74 66 2860 15860
6000 86 78 69 2870 16860

FHE(1000)-30

(6000person/h)

Speed:0.5m/s

3000 63 59 53 2750 10900
3500 67 64 57 2780 11890
4000 71 68 61 2810 12880
4500 75 73 65 2830 13870
5000 83 79 71 2840 14860
5500 87 84 75 2860 15860
6000 92 88 79 2870 16860
30° Escalator Construction Layout Drawing
Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 0



Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 1



Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 2



Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 3



Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 4

Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 5



Indoor Shopping Mall Escalator Safety VVVF Energy Saving System Customized 6



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
