1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System

1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System
1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System

Large Image :  1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Parking Lift
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000-8000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Type: Rotary Parking System Load: 1800~2300kg
Drive Mode: Hydraulic Driven Keywords: Auto Parking Lift
Power: 380V Application: Car Parking Elevator
Model: Rotary Parking System Product: Rotary Parking System
High Light:

380V Rotary Parking System

,

2300kg Load Rotary Parking System

,

Rotary Auto Parking Lift

380V Rotary Parking System The Most Space-Efficient Parking System



●Carousel parking system is the best mechanical independent parking at streets.

●The most space-efficient parking system as you can park up to 16 cars in a
space 5.5 m width x 6.5 m length.
●Different models with 8,10,12,14&16 car spaces for either Sedan and SUuvcars according to permissible site height.
●German SEW geared motor drive with roller chain & sprocket mechanism.
●Designed to park vehicles by vertically circulating cage in Cw / CCW directions.

●All cages are moving simultaneously through heavy duty conveyor sprocket shaft.

●Simple operation through push button controls / lC cards.
●Electric panel is equipped with PLC,Schneider type.
●Steel parts are shot blasted then powder coated with desired color.







Model SN-PCX12D SN-PCX12H
Vehicle Size 5300x1850x1550mm 5300x2100x2000mm
Lifting capacity 1800kg 2300kg
Installation Space 6500x5500x13600mm 6500x5700x16700mm
Unit Weight 25Tons 35Tons
Shipping Load 2x40HQ 2x40HQ
Operation System Integrated Gearmotors Driven+Roller Chains
Lifting/Sliding Motor 9.2Kw SEW-Germany 15Kw SEW-Germany
Voltage 380v/50Hz-60Hz/3Ph



1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System 0



1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System 1



1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System 2



1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System 3



1800 - 2300kg Load 380V Rotary Parking System Space Efficient Parking System 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
