Safety Guaranteed With High-Performance Control System For Automatic Walkway
SUNNY series of passenger conveyors
The low ramp angle of automatic walkway makes it easy for people to walk on and convenient for continuous transportation of trolleys and passengers. It can be equipped with armrest lamp belt, so that it is more high-end and classy. It is applicable to supermarkets, shopping plazas;
The low ramp angle of automatic walkway makes it easy for people to walk on and convenient for continuous transportation of trolleys and passengers. It can be equipped with armrest lamp belt, so that it is more high-end and classy. It is applicable to supermarkets, shopping plazas;
Automatic walkway can be used for long distance horizontal transportation.
It is applicable to airports.
Automatic walkway has multiple operation modes, which can efficiently save electricity for customers and improve the efficiency of building utilization rate through VVVF frequency conversion technology. By using frequency conversion energy saving technology, automatic walkway can effectively reduce energy consumption by 38%.
Walkway ensures passenger safety from hardware to software. With high-performance dual 64-bit control chip, SUNNY’s automatic walkway control system can be stably applied to logic or power drive and other control technologies at high speed, and fully control the safe operation of the automatic walkway.
In order to better avoid the accident of pinching during the use of the product, automatic walkway is equipped with a full-coverage anti-pinch device.
Automatic walkway can double detect the operation of the main engine and pedal, and effectively prevent and solve the occurrence of reversal accidents. Its streamlined escalator design adopts the principle of life engineering, giving it elegant lines.
| Moving walk |
Moving walkway, travelator, passenger conveyor, sidewalk, autowalk |
| Span Length |
L≤105000mm |
| Step Width |
800mm, 1000mm, 1200mm, 1400mm |
| Inclined Degree |
0°, 10°, 11°, 12° |
| Speed |
0.5m/s, 0.65m/s |
| Noise |
≤65dB |
| Vibration |
≤35cm/s² |
| Running |
Single speed up &down reversible |
| Delivery |
40ft high container |
| Power Supply |
Power 380V , 50Hz Three Phase Five Wire System
Lighting 220V, single phase |
| Energy Saving Function |
VVVF, Auto start stop |
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
