Home ProductsResidential Home Elevators

Factory Price Newest 3 Floor Small Lift Platform Home House Elevator

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

Factory Price Newest 3 Floor Small Lift Platform Home House Elevator

Factory Price Newest 3 Floor Small Lift Platform Home House Elevator
Factory Price Newest 3 Floor Small Lift Platform Home House Elevator

Large Image :  Factory Price Newest 3 Floor Small Lift Platform Home House Elevator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Freight Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: House Elevator Load: 250~400kg
Speed: 0.4m/S Application: House Elevator
Warranty: 12 Months After Shipping Keywords: House Elevator
Usage: House Elevator Drive Type: AC
Model: House Elevator Type: House Elevator
Highlight:

CE Certificates House Elevator

,

Small Lift Platform Home Elevators

,

3 Floor Residential Home Elevators

Factory Price Newest 3 Floor Small Lift Platform Home House Elevator





Machine Room Less
Loading Passenger Loading Capacity Speed Car Size Shaft(Min.) Overhead Height Pit
Passenger (Kg) (m/s) W*D*H(mm) W*D(mm) H(mm) H(mm)
3 250 0.4 950*1000*2200 1600*1350 3600 650
4 320 0.4 1000*1050*2200 1650*1400 3600 650
5 400 0.4 1050*1100*2200 1700*1450 3600 650



Elevator Funtion:

Travel Funtion
VVVF drive Motor rotating speed can be precisely adjusted to get sommth speed curve in elevator's start,travel and stop and gain the sound comfort.
VVVF door operator Motor rotating speed can be precisely adjusted to get the more gentle and senslitive dppr machine start/stop
Independent Running The elevator can not respond to outer calling,but only respond to the command inside the car through the action switch.
Automatic pass without stop When the car is crowed with the passengers or the load closed to preset value,the car will automatically pass the calling landing in order to keep maximum travel efficiency
Auto adjust door opening time Door-open time can be automatically adjusted according to the difference between landing calling or car calling.
Reopen with hall call In the door closing process,press reopen with hall call button can restart the door
Express door closing When the elevator stops and opens the door,press door-close button,the door will be closed immediately.
Car stops and door open The elevator decelerates and levels,the door only opens after the elevator comes to a complete stop.
Car arrival gong Arrival gong in the car top anniunces that the passengers arrive.
Command register cancel If you press the wrong floor command button in the car,twice continuous pressing of the same button can cancel the register commend.
Direct parking It completely accords with distance principle with no crawling in the leveling.it greatly enhances the travel efficiency



Optional Function
Leveling when power failure In the normal power failure ,the chargeable battery supplies the elevator power.The elevator drives to the nearest landing.
Bell In emergency conditions,if bell button above car operation panel is continuously pressed,electric bell rings on the top of the car.
Anti-nuisance In the light duty load,when three more commands appear,in the order avoid the unnecessary parking.all the registered calling in the car will be cancelled.
Open the door in advance When the elevator decelerates and enters into door open zone,it automatically opens the door to enhance the travel efficiency.
On-duty peak service Within the preset off-duty period,the elevators are continuously clispatched to top floor in order to satisfy off-duty peak service.
Door open time extending Press special button in the car,the elevatordoor keeps open for certain peroid time.
Door-opening re-leveling When the elevator door opens and leveling flutuation occurs due to change of the car load,the system automatically runs the elevator to leveling position by its own leveling speed under the conditions of door-opening.
Voice Announcer When the elevator normally arrives,voice announcer informs the passengers about the relevant information.
Operation box for the disabled It is convenient for the wheelchair passengers and those who have visual disorder
IC card control funtion All (Partial) landings can only input car commands though LC card after the authorization
Camera funtion in the car The camara is installed in the cabin to monitor the carbin conditions



Factory Price Newest 3 Floor Small Lift Platform Home House Elevator 0



Factory Price Newest 3 Floor Small Lift Platform Home House Elevator 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
