1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted

1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted
1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted

Large Image :  1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Machine Roomless Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Machine Roomless Elevator Load: 450kg-1600kg
Speed: 0.5~2.5m/s Persons: 6-21
Car Wall: Mirro Stainless Steel And Hairline Stainless Steel Foor: PVC
Machine Room: Without Certification: ISO, CE Certificate
Machine: Gearless Voltage: 380V/220V
Model: Machine Roomless Elevator Type: Machine Roomless Elevator
High Light:

1600kg Passenger Machine Roomless Elevator

,

Stainless Steel Hairline Passenger Elevator

,

Painted Machine Roomless Elevator

1600kg Passenger Machine Roomless Elevator With Stainless Steel Hair Line/Painted





Load(kg) Person Speed(m/s) Door Opening(mm) Cabin Size(mm) Shaft Size(AH*BH) Pit Depth Head Room Height(mm)
450 5 0.50 700*2100 1150*1100 1700*1800 ≥ 1500 ≥ 3500
630 8 1.0-1.5 800*2100 1300*1250 1850*1900 ≥ 1500 ≥ 3500
800 10 1.0-1.75 800*2100 1500*1300 2050*1950 ≥ 1500 ≥ 3500
10 1.0-1.75 900*2100 1500*1300 2050*1950 ≥ 1500 ≥ 3500
1000 13 1.0-2.5 900*2100 1600*1500 2150*2150 ≥ 1500 ≥ 3500
1250 16 1.0-2.5 1000*2100 1750*1600 2300*2250 ≥ 1500 ≥ 3500
1600 21 1.0-2.5 1100*2100 2050*1700 2600*2450 ≥ 1500 ≥ 3500
We can also desgin according customer requirement for approved residential elevators



Gearless&Machine Room / Gearless&Roomless / Geared&Roomless
Power Supply: 380V
Main Frequency: 50Hz
Light Curtain: Weco
Landing Door Type: Central/Left/Right
Wing Board: Hairline finish
Car Floor Decor: Customer Require for approved residential elevators
Car Deco: Stainless steel Hair line/Painted
Celling: According Type or Customer Requirement
Car Side and Car back: Center board: Mirror finished, Hairline finish



1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted 0


1600kg Passenger Machine Roomless Elevator With Stainless Steel Hairline / Painted 1



FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.


2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.


3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.


4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
