Product Details:
Payment & Shipping Terms:
|
| Name: | Passenger Elevator | Load: | 450~1600kg |
|---|---|---|---|
| Speed: | 1.0~1.75m/S | Control System: | VVVF Drive |
| Material: | Stainless Steel 304 | Application: | Home Usage |
| Elevator Type: | Passenger Elevator | Model: | Passenger Elevator |
| High Light: | Home Passenger Elevator VVVF,Stainless Steel Home Passenger Elevator 304,Home Residential Passenger Lifts |
||
Standard Function
VVVF drive
VVVF door operator
Independent running
Automatic pass without stop
Automatically adjust door opening time
Reopen with hall call
Express door closing
Car stops and door opens
Car arrival gong
Command register cancel
Photocell protection
Designated stop
Overload holding stop
Anti-stall timer protection
Start protection control
Inspection operation
Fault self-diagnosis
Repeated door closing
Up/down over-run and final limit protection
Down over-speed protection device
Upward over-speed protection device
Micro-touch button for car call and hall call
Floor and direction indicator inside car
Floor and direction indicator
Emergency car lighting
Inching running
Five way intercom
Bell
Fire emergency return
Car ventilation, light automatic shut off
Remote shut-off
|
Loading Capacity/ Passengers |
Rated Speed (m/s) |
Door Opening Size (mm) (JJ×HH) |
Door Opening Type |
Car Size (mm) (AA×BB) |
Hoistway Size (mm) |
Machine Room Size (mm) (W×H) |
||
|
AH×BH |
PP |
OH |
||||||
|
450kg/ 6 Passengers |
1.0 | 800×2100 | Center Opening | 1400×850 | 2000×1550 | 1500 | 4500 | 2000×1550 |
| 1.5 1.75 | 1600 | |||||||
|
630kg/ 8 Passengers |
1.0 | 800×2100 | Center Opening | 1400×1100 | 2000×1750 | 1500 | 4500 | 2000×1750 |
| 1.5 1.75 | 1600 | |||||||
|
800kg/ 10 Passengers |
1.0 | 800×2100 | Center Opening | 1400×1350 | 2000×2000 | 1500 | 4500 | 2000×2000 |
| 1.5 1.75 | 1600 | |||||||
|
1000kg/ 13 Passengers |
1.0 | 900×2100 | Center Opening | 1600×1400 | 2200×2150 | 1500 | 4500 | 2200×2150 |
| 1.5 1.75 | 1600 | |||||||
|
1250kg/ 16 Passengers |
1.0 | 1100×2100 | Center Opening | 2000×1400 | 2600×2150 | 1500 | 4500 | 2600×2150 |
| 1.5 1.75 | 1600 | 4700 | ||||||
|
1350kg/ 18 Passengers |
1.0 | 1100×2100 | Center Opening | 2000×1500 | 2600×2250 | 1500 | 4500 | 2600×2250 |
| 1.5 1.75 | 1600 | 4700 | ||||||
|
1600kg/ 21 Passengers |
1.0 | 1100×2100 | Center Opening | 2000×1750 | 2600×2500 | 1500 | 4500 | 2600×2500 |
| 1.5 1.75 | 1600 | 4700 | ||||||
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
