4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift

4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift
4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift

Large Image :  4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: 4 Post Double Deck Parking Lift
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000-8000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Type: 4 Post Double Deck Parking Lift Load: 3000kg
Drive Mode: Hydraulic Driven Keywords: Auto Parking Lift
Power: 220V/380V Application: Car Parking Elevator
Model: 4 Post Double Deck Parking Lift Product: 4 Post Double Deck Parking Lift
High Light:

Hoist Car Storage Lift 4 Post

,

Double Deck Hydraulic Parking Lift

,

Hydraulic Car Parking Elevator

Hydraulic 4 Post Auto Hoist Parking Car Storage Lift Parking 4 Post Double Deck Parking Lift



Lifting capacity
3000kg
Net weight
750kg
Max lifting height
1860mm
Runway min height
150mm
Height of columns
2190mm
Runway width
475mm
Capacity of motor
2.2KW
Power supply
110/220/380V, 50/60Hz



Features:
1, 3000kg maximum lifting capacity;
2, Single hydraulic cylinder mounted underneath runway;
3, Ideal choice for simple vehicle services and vehicle parking in families or commercial parking lot;
4, Manual release, simple and convenient;
5, Optional mobile kit can make the whole lift move easily in your garage;
6, Low profile design for easier driving-on;
7, The mechanical safety lock automatically engaged when rising;
8, Standard oil drip tray protects the vehicle below from being contaminated;



4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift 0



4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift 1



4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift 2



4 Post Auto Hoist Car Storage Lift Hydraulic Double Deck Parking Lift 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
