Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door

Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door
Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door

Large Image :  Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Residential Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Hydraulic Home Elevator Load: 320~400kg
Speed: 0.4m/s Elevator Door: Center Opening Door
Warranty: 1 Year Type: Elevators
Elevator Type: Hydraulic Home Elevator Application: Home Usage
Model: Hydraulic Home Elevator
High Light:

Residential Hydraulic Home Elevator

,

Home Lift Elevator Custom

,

House Elevator Lift Indoor

Hyundai Custom Hydraulic Home Elevator Home Lift Indoor Small Elevators



Customized panoramic elevator design supporting by our professional technical team .



Capacity (kg) Speed (m/s) Car size (mm) Open size (mm) Hoistway size (mm) Pit depth (S) Overhead height (K)
320 0.4 1000*1000*2200 (cw*cd*chr) 700*2000 (op*oph) 1700*1400 (hw*hd) 500mm 3300mm
400 1200*1000*2200 (cw*cd*chr) 1900*1400 (hw*hd)



Capacity (kg) Other position size (mm) Supporting force (kN)
/ w1 w2 hw1 hw2 hd1 ctc1 e1 l4 R1 R2 R3 R4 R5 RR
320 470 330 970 730 660 825 705 400 40 30 12 10 10 15
400 620 380 1070 830 660 925 805 500





Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door 0



Custom Hydraulic Residential Home Elevators Indoor 0.4m/S Center Opening Door 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
