Product Details:
Payment & Shipping Terms:
|
| Name: | Mrl Gearless Elevator | Type: | Mrl Gearless Elevator |
|---|---|---|---|
| Load: | 2000~3500kg | Application: | Warehouse |
| Speed: | 1~1.75m/s | Overhead: | 4500mm |
| Warranty Time: | One Year | Voltage: | 380V/220V |
| Model: | Machine Roomless Passenger Lift | Product: | Machine Roomless Passenger Lift |
| Product Name: | Machine Roomless Passenger Lift | ||
| High Light: | Gearless Machine Roomless Passenger Lift,380V Machine Roomless Passenger Lift,Machineless Elevator With Call System |
||
Machine Roomless Passenger Lift Elevator With Elevator Call System Via Smartphone
How MRL elevators work
Machine-room-less elevators utilize a gearless traction machine located in the hoistway. The use of a counterweight assists the machine in turning the elevator sheave, which moves the cab through the hoistway. Most commonly seen in hotels, apartments, mixed-use buildings and commercial offices, MRL elevators can handle 2 to 25 stops (with a typical capacity of 2,100 to 5,000 lbs.) and feature flexible design. Large capacities (4,000 lbs. and above) can accommodate heavier cab finishes.
| Opening | Front Opening | Front Opening | Front Opening | Front Opening |
|---|---|---|---|---|
| Capacity (lbs.) | 2000/Passenger | 2500/Passenger | 3000/Passenger | 3500/Passenger |
| Speed (fpm) | 200, 350, 400, 500 | 200, 350, 400, 500 | 200, 350, 400, 500 | 200, 350, 400, 500 |
| Hoistway (w x d) | 7’ 6” x 6’ - 11” | 8’ 6” x 6’ 11” | 8’ 6” x 7’ 4” | 8’ 6” x 8’ |
| Platform (w x d) | 6’ x 5’ 1” | 7’ x 5’ 1” | 7’ x 5’ 6” | 7’ x 6’ 2” |
| Inside Clear | 5’ 8” x 4’ 3 ¾” | 6’ 8” x 4’ 3 ¾” | 6’ 8” x 4’ 8 ¾” | 6’ 8” x 5’ 4 ¾” |
| Door Type | SS | SS, CO | SS, CO | SS, CO |
| Entrance Width | 3’ | 3’ 6” | 3’ 6” | 3’ 6” |
| Pit (200 fpm) | 5’ 5 ½” | 5’ 5 ½” | 5’ 5 ½” | 5’ 5 ½” |
| Pit (350 fpm) | 5’ 11 ½” | 5’ 11 ½” | 5’ 11 ½” | 5’ 11 ½” |
| Pit (400 fpm) | 6’ 3” | 6’ 3” | 6’ 3” | 6’ 3” |
| Pit (500 fpm) | 7’ 5” | 7’ 5” | 7’ 5” | 7’ 5” |
| Overhead (200 fpm)* | 14’ 3” | 14’ 3” | 14’ 3” | 14’ 3” |
| Overhead (350 fpm)* | 14’ 6” | 14’ 6” | 14’ 6” | 14’ 6” |
| Overhead (400 fpm)* | 15’ 5” | 15’ 5” | 15’ 5” | 15’ 5” |
| Overhead (500 fpm)* | 16’ 3” | 16’ 3” | 16’ 3” | 16’ 3” |
| Maximum Travel (200 fpm) | 75’ | 75’ | 75’ | 75’ |
| Maximum Travel (350 fpm) | 98’ 5” | 98’ 5” | 98’ 5” | 98’ 5” |
| Maximum Travel (400/500 fpm) | 262’ 5” | 262’ 5” | 262’ 5” | 262’ 5” |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
