1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift

1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift
1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift

Large Image :  1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Machine Roomless Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Machine Room Less Elevator Type: Mrl Gearless Elevator
Load: 630~1600kg Application: Warehouse
Speed: 1~1.75m/s Overhead: 4500mm
Warranty Time: One Year Voltage: 380V/220V
Model: Machine Room Less Elevator Product: Machine Room Less Elevator
High Light:

Passenger Machine Room Less Lift

,

1.75m/S Machine Less Lift

,

Roomless Building Passenger Lift

Machine Roomless Small Building Passenger Lift Elevator For Hotel/Office

1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift



What is machine room less elevators?

Machine room less elevators (usually shortened to as M.R.L. or MRL) are a type of either traction or hydraulic elevator which do not require a machine room for the elevator.



Load Speed Car size

Door opening

size

Shaft size

Maximum

landing

Maximum

lifting height

kg m/s CW CD CH OP OPH HW HD K S
630 1 1100 1650 2500 700 2100 2400 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
800 1 1350 1850 2500 900 2100 2500 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
1000 1 1600 1950 2500 900 2100 2550 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
1350(widecar) 1 1500 1950 2500 1100 2100 2850 2000 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1350(deepcar) 1 2300 2250 2500 1100 2100 2150 2800 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1600(widecar) 1 1700 1950 2500 1100 2100 2850 2100 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1600(deepcar) 1 2400 2250 2500 1200 2100 2250 2900 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90



1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift 01.75m/S VVVF Machine Room Less Elevator Building Passenger Lift 1



1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift 2

1.75m/S VVVF Machine Room Less Elevator Building Passenger Lift 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
