Center Opening Door Customized Panoramic Home Elevator Lift 1600kg load

Certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
China SHANGHAI SUNNY ELEVATOR CO.,LTD certification
With the arrival of the new year, I wish the company will expand its scale, develop its business, develop its business and expand its financial resources.

—— Melya

Insisting on Product Quality Management, Building Long-term Effective Mechanism of Quality. It's a pleasure to cooperate with you.

—— Yuilly

I'm Online Chat Now

Center Opening Door Customized Panoramic Home Elevator Lift 1600kg load

Center Opening Door  Customized Panoramic Home Elevator Lift 1600kg load
Center Opening Door  Customized Panoramic Home Elevator Lift 1600kg load Center Opening Door  Customized Panoramic Home Elevator Lift 1600kg load

Large Image :  Center Opening Door Customized Panoramic Home Elevator Lift 1600kg load

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 450-1600kg
Speed: 1.0-3.0m/s Handrail: Stainless Steel/wooden/others
Warranty: 12 Months After Shipping Application: Office Building
Usage: Passenger Elevator Control System: VVVF Elevator Control System
High Light:

1600kg center opening panoramic lift

,

1600kg Customized panoramic Lift

,

center opening door panoramic lift



Center Opening Mirror Golden Manual Door Customized Home Passenger Elevator Lift



Specifications:

Passenger elevators descriptions with small machine room :

Small Machine Room Available Specifications

Persons Rated Capacity(KG)

Rated Speed

(m/s)

Model Number

Inner Dimension

(mm)

Size of Door(mm) Hoistway Size(mm) Machine Room Dimension
6 450 1.0-1.75 FAK450 1300×950 700×2100 1800×1650 1800×2000×2500
8 630 1.0-1.75 FAK630 1400×1100 800×2100 2000×1750 2000×2000×2500
10 800 1.0-3.0 FAK800 1400×1350 800×2100 2000×2000 2000×2000×2500
12 900 1.0-3.0 FAK900 1400×1500 900×2100 2000×2200 2000×2200×2500
13 1000 1.0-3.0 FAK1000 1600×1400 900×2100 2200×2100 2200×2100×2500
15 1150 1.0-3.0 FAK1150 1600×1600 900×2100 2200×2300 2200×2300×2500
16 1250 1.0-3.0 FAK1250 1750×1600 1000×2100 2350×2300 2350×2300×2500
18 1350 1.0-3.0 FAK1350 1800×1650 1000×2100 2400×2400 2400×2400×2500
21 1600 1.0-3.0 FAK1600 1950×1750 1100×2100 2900×2300 2900×2300×2500





Center Opening Door  Customized Panoramic Home Elevator Lift 1600kg load 0



Center Opening Door  Customized Panoramic Home Elevator Lift 1600kg load 1



About Us
SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.

SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.


FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
