Product Details:
Payment & Shipping Terms:
|
| Name: | Roomless Passenger Elevator | Load: | 450-2000kg |
|---|---|---|---|
| Speed: | 0.6-3.0m/s | Handrail: | Stainless Steel/wooden/others |
| Warranty: | 12 Months After Shipping | Application: | Office Building |
| Usage: | Passenger Elevator | Control System: | VVVF Elevator Control System |
| Model: | Roomless Passenger Elevator | Type: | Roomless Passenger Elevator |
| High Light: | 1000kg roomless passenger elevator,Office Building roomless Passenger Elevator,1000kg mrl passenger elevator |
||
Lift Elevator Passenger Elevator For Commercial Building With VVVF Elevator Control System
1000kg Commercial Building MRL Roomless Passenger Elevator With Elevator Wire Rope
|
Type:
|
Machine room type
|
Machine room less type
|
||
|
Speed:
|
0.6-3.0, if speed above 3.0 will be complete customized solution (max to be 7m/s)
|
0.6-1.75, if speed above 2.0 please check with our sales for availablity
|
||
|
Load:
|
450kg, 630kg, 800kg,1000kg,1050kg, 1150kg, 1350kg, 1600kg, 2000kg (if exceed the range please check with our sales)
|
450kg, 630kg, 800kg,1000kg,1050kg, 1150kg, 1350kg, 1600kg (if exceed the range please check with our sales)
|
||
|
Travellng Height:
|
2.66m-150m
|
2.66m-75m
|
||
|
Max Floor:
|
63
|
28
|
||
|
Max. Car group:
|
8
|
8
|
||
|
Max start per hour:
|
180
|
180
|
||
|
Leveling accuracy:
|
±5mm
|
±5mm
|
||
|
Open/Close door time:
|
≤4.0 sec(Opening width ≤1100mm)
|
≤4.0 sec(Opening width ≤1100mm)
|
||
|
Max. sill bearing:
|
0.4 x rated load weight
|
0.4 x rated load weight
|
||
|
Motor isulation class:
|
F
|
F
|
||
|
Steel rope safety co-efficient:
|
12
|
12
|
||
|
Cabn inside noise:
|
≤55dB(A)
|
≤55dB(A)
|
||
|
Ventilation:
|
4.5±0.5m³/min
|
4.5±0.5m³/min
|
||
LUXURY CABIN sunny elevator.pdf
About Us
SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.
SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
