400kg Resident Pvc Floor Display Dot Matrix Small Villa Elevator Lift For Homes

Large Image : 400kg Resident Pvc Floor Display Dot Matrix Small Villa Elevator Lift For Homes

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	3C,CE
Model Number:	Villa Elevator

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$7000~12000
Packaging Details:	container
Delivery Time:	15~30 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	500 Set/ Year

Contact Now

Detailed Product Description

Name:	Villa Elevator	Load:	320-400kg
Speed:	0.4m/s	Handrail:	Stainless Steel/wooden/others
Warranty:	12 Months After Shipping	Application:	Office Building
Floor:	PVC	Drive Type:	AC
Model:	Villa Elevator	Type:	Villa Elevator
Highlight:	pvc floor villa lift , pvc floor villa elevator , 400kg load villa elevator

Fuji Elevator 400kg Resident Indoor Small Villa Elevator And Lift Homes

Persons	Capacity(kg)	Speed(m/s)	Inner Dimension W x D (mm)	Door Opening Size W x D (mm)	Hoistway Size W x D (mm)
4	320	0.4	900x1100	(Right opening)800x2100	1550x1500
4	320	0.4	1000x1000	(center opening) 700x2100	1650x1400
5	400	0.4	900x1200	(Right opening)800x2100	1550x1600
5	400	0.4	1000x1100	(center opening) 700x2100	1650x1500

Capacity(kg)	Rate speed(m/s)	Top Floor Height (mm)	Pit Depth (mm)
320~400	0.4	≥3500	≥600

Ceiling	Integrated mirror stainless steel with lighting
Control Panel	integrated, titanium black mirror stainless steel finished
Display	Dot Matrix
Control Panel Button	Round
Rear Car Wall	Hairline stainless steel with etching
Car Side Wall	Hairline stainless steel
Car Door and Landing Door	Stainless steel
Car Floor	PVC floor

Construction Sketch

400kg Resident Pvc Floor Display Dot Matrix Small Villa Elevator Lift For Homes 0

STANDARD CONFIGURATION

FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.

2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.

3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.

4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
