0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width

0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width
0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width

Large Image :  0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: MOVING WALK
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Outdoor Moving Walkway Width: 800-1400mm
Angle: 0-12 Degree Keywords: Moving Walk
Motor Power: 380V/50Hz/3p Speed: 0.5M/S
Specification: CE; IS9001; IS14001 Energy Saving Function: VVVF
Model: Outdoor Moving Walkway Type: Outdoor Moving Walkway
Highlight:

High Efficient Moving Walkway

,

0.5m/S Speed Moving Walkway

,

1400mm Width Moving Walkway

0.5m/S High Efficient High Quality Indoor & Outdoor Moving Walkway



A moving walkway, also known as an autowalk,moving pavement,moving sidewalk,people-mover, travolator,or travelator,is a slow-moving conveyor mechanism that transports people across a horizontal or inclined plane over a short to medium distance.Moving walkways can be used by standing or walking on them. They are often installed in pairs, one for each direction.



Moving walk Moving walkway
Span Length L≤105000mm
Step Width 800mm, 1000mm, 1200mm, 1400mm
Inclined Degree 0°, 10°, 11°, 12°
Speed 0.5m/s, 0.65m/s
Noise ≤65dB
Vibration ≤35cm/s²
Running Single speed up &down reversible
Delivery 40ft high container
Power Supply Power 380V , 50Hz Three Phase Five Wire System
Lighting 220V, single phase
Energy Saving Function VVVF, Auto start stop



0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width 0

0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width 1

0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width 2



0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width 3

0.5m/S High Efficient Indoor Outdoor Moving Walkway 1400mm Width 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
