0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons

0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons
0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons

Large Image :  0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Villa Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Small Residential Elevators Load: 250~400kg
Speed: 0.25m/s Power Supply: 3 Phase, 380V, 50Hz
Application: Home Usage Pit: 200mm
Material: Mirror Etched Stainless Steel Type: Small Residential Elevators
Model: Small Residential Elevators Product: Small Residential Elevators
Highlight:

Machine Room home elevator lift

,

0.25m/s home elevator lift

,

0.25m/s small residential elevator

Machine Room House Residential Lift With Villa Passenger Home Elevator

0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons



Passenger elevator lift utilizes the advanced lift control technology, which is advanced variable frequency variable voltage (VVVF) drive combined with fully computer control technology with the data net system and modularized structure.



It brings a more precise, efficient, flexible and reasonable systematic controlling. It also adopts the most effective self-inspection program to give a full play of the lift functions. It moves the lift performance to a higher level. Truly satisfies the passengers’ requirement.



Standard Specification

Load Capacity 250kg/320kg/400kg
Rated Speed 0.25m/s
Rated Load 3 persons/4 persons/5 persons
Lifting Height 12m
Max. Stops 5 stops (floor height is 3m)
Hoistway Size (mm) 1200W*1200D/1300W*1300D/1300W*1500D
Platform Size (mm) 800W*1100D/900W*1200D/900W*1400D
Opening Size (mm) 800W*2000H
Door Open Type Manual open/ Automatic one side open
Door Type Single door or opposite door
Overhead (mm) 2700
Pit (mm) 200



0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons 0



 0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons 1



0.25m/S Machine Room Small Residential Elevators 3 Phase 5 Persons 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
