| Name: | Home Passenger Lift | Load: | 320kg -400kg |
|---|---|---|---|
| Speed: | 0.4m/s | Handrail: | Stainless Steel/wooden/others |
| Warranty: | 12 Months After Shipping | Deceleration Device: | With Deceleration Device |
| Elevator Door: | Center Opening Door | Door Knife: | Single |
| Model: | Home Passenger Lift | Type: | Home Passenger Lift |
| High Light: | 320kg private passenger lifts,320kg wooden home lifts,MRL private home lifts |
||
400kg Hot Sale Safety Small Home Lift Residential Elevator Price
MRL Machine Roomless 320kg Wooden Private Home Passenger Lift
Passenger elevator are designed for different types of residential buildings, villas residential, office buildings.
Passenger elevator for homes have high performance elevator parts, permanent magnet synchronous drive and intelligent door system, safe and reliable.
Passenger elevator for homes permanent magnet synchronous traction machine, smaller volume but higher efficiency, saving more space for the headroom.
Passenger elevator highest safty standard, to ensure passenger safty.
Passenger elevator multiple customized for the transportation arrangement and structure for matching the design style of house.
Profession Commercial Passenger Elevator with Low Price
Profession Home Lift Product Description:
1. Material: wooden; Hairline stainless steel, mirror, etched, Titanium gold, rose gold, golden recess, glass;
2. Capacity: 320kg, 400kg
3. Speed: 0.4m/s, 0.6m/s, 1.0m/s,
4. Machine Room: Machine Room (MR) or Machine Roomless (MRL)
5,construction:Gantry, backpack rack
| Application | Residential,Hotel,Office | ||||
| Loading(Kg) | 630 | 800 | 1000 | 1350 | 1600 |
| Speed(m/s) | 1.0/1.75 | 1.0/1.75/2.0 | 1.0/1.75/2.0 | 1.0/1.75/2.0/2.5 | 1.0/1.75/2.0/2.5 |
| Door Control | VVVF | ||||
| Opening Width(m) | 800*2100 | 800*2100 | 900*2100 | 1100*2100 | 1100*2100 |
| Headroom(m) | 4.0-4.5 | ||||
| Pit Depth (m) | 1.5 | 1.5-1.7 | 1.5-1.8 | 1.8-2.0 | 1.8-2.0 |
| Total Height(m) | <150m | ||||
| Stop | <56 | ||||
| Brake voltage | DC110V | ||||
| Power | 380V,220V,50HZ/60HZ | ||||
Construction Sketch
STANDARD CONFIGURATION
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
