Product Details:
Payment & Shipping Terms:
|
| Name: | Hospital Elevator | Load: | 1000~1600kg |
|---|---|---|---|
| Door Knife: | Without Attendant | Driving Type: | Vvvf |
| Car Door: | Hairline Stainless Steel | Car Wall: | Hairline Stainless Steel |
| Usage: | Hospital Elevator | Application: | Hospital |
| Model: | Hospital Elevator | ||
| High Light: | Hairline Stainless Steel Hospital Elevator,Vvvf Hospital Elevator |
||
Stable and Low Noise Hospital Elevator From Professional Manufacturer
CE Hairline Stainless Steel Vvvf Hospital Elevator Without Attendant
************************************************
For detail information, please contact us.
************************************************
Hospital elevator construction parameters
| Load(kg) | Speed(m/s) | Car size(mm) | Door opening size(mm) | Hoistway size(mm) | Machine room size |
Pit depth(mm) | Top floor height(mm) | Max.travelling height(m) |
| CW*CD*CH | OP*OPH | HW*HD | ||||||
| 1000 | 1.0 | 1100*2100*2500 | 900*2100 | 2100*2600 | 2100*2600*2800 | 1500 | 4500 | 25 |
| 1.5 | 1600 | 4600 | 50 | |||||
| 1.75 | 1700 | 4700 | 90 | |||||
| 1000 | 1.0 | 1100*2100*2500 | 1000*2100 | 2000*2700 | 2000*2700*2800 | 1500 | 4500 | 25 |
| 1.5 | 1600 | 4600 | 50 | |||||
| 1.75 | 1700 | 4700 | 90 | |||||
| 1600 | 1.0 | 1400*2400*2500 | 1100*2100 | 2550*2900 | 2550*2900*3000 | 1500 | 4500 | 25 |
| 1.5 | 1600 | 4600 | 50 | |||||
| 1.75 | 1700 | 4700 | 90 | |||||
| 1600 | 1.0 | 1400*2400*2500 | 1200*2100 | 2350*3000 | 2350*3000*3000 | 1500 | 4500 | 25 |
| 1.5 | 1600 | 4600 | 50 | |||||
| 1.75 | 1700 | 4700 | 90 |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
