Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System

Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System
Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System

Large Image :  Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Type: Passenger Elevator Load: 450~1000kg
Trademark: SAFE ELEVATOR Specification: 20GP/40HQ
Transport Package: Wooden Box For Export Elevator Door: Center Opening Door
Drive Type: AC Control System: VVVF Elevator Control System
Keywords: Passenger Elevator Warranty: 12 Months After Shipping
Model: Passenger Elevator
High Light:

gearless Passenger Elevator

,

Load 1000kg Passenger Elevator

,

Passenger Elevator VVVF Elevator Control

Load 450~1000kg Energy-Saving Passenger Elevator From China Manufacturer

Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System



Our advantage

1. Compact and cost-effective: its gearless construction helps to save construction costs and beautify the building's appearance.
2. Rugged and reliable: The gearless construction reduces consumable parts, enhances reliability and adds a safety factor to the elevator.
3. Energy saving and environmental protection: directly saves the cost of cooling and cooling compared to the traditional drive system.



Persons

Load

(kg)



Speed

(m/s)



Net size of car(mm)

C.WxC.DxD.H



Net size of door(mm)

2P Center opening



Shaft size(mm) Machine room size(mm)
H.WxH.D HR.H PIT MR.WxMR.D MR.H
6 450 1.0 1400x850x2300 800x2100 2000x1500 4000 1500 2000x1500 2500
1.5/1.75 4400
8 630 1.0 1400x1100x2300 800x2100 2000x1720 4200 1500 2000x1720 2500
1.5/1.75 4400 1600
10 800 1.0 1400x1350x2300 800x2100 2000x1970 4200 1500 2000x1970 2500
1.5/1.75 4400 1600
2.0 4800 1800
2.5 2000
13 1000 1.0 1600x1450x2300
1100x2100x2300
Stretcher elevator
900x2100 2200x2120
2100x2500
Stretcher elevator
4200 1500 2200x2120
2100x2500
Stretcher elevator
2500
1.5/1.75 4400 1600
2.0 4800 1800
2.5 2000
3.0 5200 2600
3.5 5500 3100
4.0 6000 3850



Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System 0



Compact Gearless Load 1000kg Passenger Elevator With VVVF Elevator Control System 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
