Product Details:
Payment & Shipping Terms:
|
Type: | CLEAR FLOOR TWO POST CAR LIFT | Load: | 3500~5000kg |
---|---|---|---|
Total Height: | 1850mm | Keywords: | Clear Floor Two Post Car Lift |
Gross Weight: | 680kg | Power Supply: | 220V/380V |
Certification: | CE,ISO9001 | Warranty: | 12 Months After Shipping |
Product Name: | Smart Car Parking System | Product: | Smart Car Parking System |
Use: | Smart Car Parking System | ||
Highlight: | hydraulic lift for car parking,double stack car lift |
OT SALE 2 Post Car Lift 4T High Ceiling CLEAR FLOOR Two Side Release CE Approved
Product features
Dual-cylinder hydraulic driven and wire rope balance system.
Lifting carriages connected to cylinders, sliding on the posts.
High polymer polyethylene slide blocks, wear-resistance
Extra width between two posts without floor plate.
Automatic safety locks, manual lock release system.
Limiting displacement bar with limit switch to stop lifting in the highest position.
Adjustable lifting height to suit any type of cars.
3 stages swing arms to fit long cars.
Optional electric control panel IP 65 with high quality components (CHINT)
Polyurethane durable screw/ fixed pads and free high adapters
Steel parts are sandblasted then anti-corrosion primer painted and top finish color coated.
CE Certified according to EC machinery directive 2006/42/CE
Product parameters | ||||
Model NO | LTC35/1850-2J | LTC40/1850-2J | LTC45/1960-3J | LTC50/1960-3J |
Lifting Capacity | 3500kg | 4000kg | 4500kg | 5000kg |
Lighting Height | 1850mm | 1850mm | 1960mm | 1960mm |
Total Height | 3670mm | 3670mm | 3860mm | 3860mm |
Gross Weight | 680kg | 720kg | 760kg | 800kg |
Arm Type |
2 Stage arms 3 Stage arms with lifting pads and extension adaptors with lifting pads and extension adaptors |
|||
Lock Release | Manual release and electric release could also be available | |||
Rise/Drop Time | 50S/40S | |||
Power Supply/Motor Capacity | 220V/380V, 50Hz/60Hz,1Ph/3Ph,2.2Kw | 3.0kw |
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
