1600kg Office Building Small Machine Room Elevator For 12 Months Warranty

1600kg Office Building Small Machine Room Elevator For 12 Months Warranty
1600kg Office Building Small Machine Room Elevator For 12 Months Warranty

Large Image :  1600kg Office Building Small Machine Room Elevator For 12 Months Warranty

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Small Machine Room ElevatorType: Small Machine Room Elevator Load: 1250-1600kg
Flooring: PVC Application: Office Building
Machine Room: Machine-room Or Machine-roomless Warranty: 12 Months After Shipping
Material: Stainless Steel 304 Control System: VVVF Elevator Control System
Model: Small Machine Room Elevator Product: Small Machine Room Elevator
Highlight:

small passenger lift

,

high speed elevator

,

1600kg Office Building Room Elevator



Fuji Brand Lift Load 1250-1600kg Small Passenger Elevator For Sale

1600kg Office Building Small Machine Room Elevator For 12 Months Warranty



What are the different types of lifts?
The different types of lifts or elevators include building lift, capsule lift, hydraulic elevator, pneumatic elevator, passenger lift, freight elevator, traction elevator/cable driven, residential elevators, machine room-less elevator, etc.



Specifications Load(kg) Speed(m/s)

Size of entra

nce(mm)

Size

of car(mm)

Size of hoist

way(mm)

Size of machine room

(mm)

Overhead heig

ht(mm)

Pit de

pth(mm)

Max travelling heig

ht(m)

1250-1.0 1250 1.0

1100*

2100

1950*

1400*2400

2550*

2050

2550*2050 4600 1600 50
1250-1.6 1.6 4650 1650 80
1250-1.75 1.75 4700 1700 120
1250-2.0 2.0 4800 1750 120
1250-2.5 2.5 5100 2200 150
1350-1.0 1350 1.0

1950*

1500*2400

2550*2150 2550*2150 4600 1600 50
1350-1.6 1.6 4650 1650 80
1350-1.75 1.75 4700 1700 120
1350-2.0 2.0 4800 1750 120
1350-2.5 2.5 5100 2200 150
1600-1.0 1600 1.0

1950*

1750*2400

2550*

2400

2550*

2400

4600 1600 50
1600-1.6 1.6 4650 1650 80
1600-1.75 1.75 4700 1700 120
1600-2.0 2.0 4800 1750 120





1600kg Office Building Small Machine Room Elevator For 12 Months Warranty 0



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
