2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved

2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved
2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved

Large Image :  2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: HIGH SPEED ELEVATOR
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Type: HIGH SPEED ELEVATOR Load: 800~1600kg
Speed: 2.0~4.0m/s Distance Of Bracket Guide Rail: 2000mm
Warranty: 12 Months After Shipping Technology: FUJI
Drive Type: AC Material: Stainless Steel 304
Control System: VVVF Elevator Control System Application: Office Building
Product: HIGH SPEED ELEVATOR Model: HIGH SPEED ELEVATOR
High Light:

small passenger lift

,

high speed elevator

,

CE Approved Commercial Elevator Lift

Commercial High Speed Lift Passenger Elevator With No Noise , CE Approved

2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved



SUNNY-Elevator.pdf



The Extremely Comfortable Travel



A shock-absorbing device is set between the car body and holder to isolate vibration. It superiorly buffers vibration during the elevator running process. It reduces the car vibration and prompts the conformable travel to vast passengers. The combined car wall connection ensures mute effects in the car, the stable and enclosed air pressure.





Load Speed Car Dimension Hoistway Dimension

Max No.

of Stops

Max Travel (m)

Min Span

Between

Various Floors

Power

KW

Distance of

Bracket Guide

Rail(mm)

DL(kg) V(m/s)

CW

(mm)

CD

(mm)

OP

(mm)

Min HW(mm) Min HD(mm) Min S(mm) Min K(mm)
800 2.0 1400 1350 800 1900 2050 1750 4700 40 120 2.7 13.5 2000
2.5 1950 4900 40 130 16.8
3.0 3600 5600 35 118 3.3 16.5
4.0 3800 5800 50 165 22.1
1000 2.0 1600 1400 900 2100 2100 1750 4700 40 120 2.7 13.5
2.5 1950 4900 40 130 16.8
3.0 3600 5600 35 118 3.3 19.7
4.0 3800 5800 50 165 26.3
1150 2.0 2000 1350 1100 2500 2100 1750 4700 40 120 2.7 16.9
2.5 1950 4900 40 130 21.3
3.0 3600 5600 35 118 3.3 22.3
4.0 3800 5800 50 165 30.1
1350 2.0 2000 1500 1100 2500 2200 1750 4700 40 120 2.7 18.4
2.5 1950 4900 40 130 23.2
3.0 3600 5600 35 118 3.3 27.2
4.0 3800 5800 50 165 36.2
1600 2.0 2000 1700 1100 2500 2400 1750 4700 40 120 2.7 21.8
2.5 1950 4900 40 130 27.5
3.0 3600 5600 35 118 3.3 33
4.0 3800 5800 50 165 53.3



2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved 0



high speed elevator

2.0m/S Commercial High Speed Elevator Lift With No Noise CE Approved 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
