Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Hospital Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Hospital Elevator Load: 1600kg
Speed: 1.0~1.75m/s Door Size: 1200x2100mm
Material: Stainless Steel Flooring: PVC
Drive Type: AC Control: VVVF Elevator Control System
Model: Hospital Elevator Type: Hospital Elevator
High Light:

hospital bed lift

,

hospital bed elevator

Bed Elevator,Bed Lift,Hospital Elevator,Hospital Lift, Medical Elevator,Medical Lift, Patient Elevator, Patient Lift, Dental Elevator

Comfortable Patient Hospital Elevator SUNNY Stainless Steel Hospital Lift



Intellectual Control System

Our intellectual control system accurately measure the location of car during the operation of elevator; The real time calculation of the system can make sure the best running time always. While the elevator acceleration, deceleration and braking, it will be more steady, the running time for each floor will be less, the leveling accuracy improved, and bring superior riding comfort.


Hospital Patient Elevator Electric Parts and Mechanical Parts Replacement

Specifications
1. Load: 1600kg
2. Speed:1.0~1.75m/s
3. Safe,Reliable & Comfortable


Load Speed Internal car size Type Door size Internal shaft size Pit depth Overhead Power
kg m/s CWxCDxCH(mm)   mm SW(min) SD(min) SW(max) SD(max) (mm) (mm) (kw)
1600 1.0 1400x2400x2400 2 panelsside folding 1200x2100 2400 2900 2800 3300 ≥1500 ≥4300 11
1.5 ≥1600 ≥4400 16.4
1.75 ≥1600 ≥4500 19.2
1600 1.0 1400x2400x2400 center open 1200x2100 2700 2900 3100 3300 ≥1500 ≥4300 11
1.5 ≥1600 ≥4400 16.4
1.75 ≥1600 ≥4500 19.2



Comfortable Patient Hospital Elevator SUNNY Stainless Steel Hospital Lift 0

Comfortable Patient Hospital Elevator SUNNY Stainless Steel Hospital Lift 1



Comfortable Patient Hospital Elevator SUNNY Stainless Steel Hospital Lift 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
