4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift

4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift
4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift

Large Image :  4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Villa Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Small Elevator Load: 260kg~400kg
Speed: 0.4m/s Pit: 800mm
Warranty: 1 Year Type: Elevators
Elevator Type: Passenger Elevators Application: Home Usage
Model: Small Elevator Product Name: Small Elevator
Highlight:

small house elevators

,

modern home elevators

Person Small Size Machine Roomless Home Lift Villa Passenger Elevator

4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift



SUNNY small machine room elevator brings about the more compact machine room layout
through small traction machine and thin control cabinet. It fulfills small machine room.
Compared with traditional elevator with machine room, it effectively reduces machine room
height and saves machine room area.



Villa elevator specifications

Persons Load(kg) Speed(m/s) Net size of car(mm) Net size of door(mm) Shaft size(mm)
C.WxC.DxD.H 2P Central opening H.WxH.D HR.H PIT
3 260 0.4 800x1150x2200 700x2000 1400x1500 3500 800
4 320 0.4 950x1300x2200 700x2000 1600x1600 3500 800
5 400 0.4 1200x1300x2200 800x2000 1850x1600 3500 800



Villa Elevator Construction Layout Drawing

4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift 0

4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift 1



4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift 2



4 Person Small Elevator For Homes , SUNNY Machine Room Less Elevator Lift 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
